Operating System
Operating SystemOperating System
Operating System
Support
SupportSupport
Support
Microsoft Windows XP
OS Driver Support
OS Driver SupportOS Driver Support
OS Driver Support
Microsoft Windows XP
Power
PowerPower
Power
Requires a 3.3-V auxiliary power rail on PCI bus
Uses only one PCI load (i.e., one grant/request pair), one shared IRQ, one
electrical load
Chipset
ChipsetChipset
Chipset
Agere Systems SV92PL – Integrated PCI interface with 5-V tolerant buffers
and CardBus support
Dimensions
Dimensions Dimensions
Dimensions
(L X H)
Complies with PCI low profile specifications-6.7 x 2.3 in (17.0 x 5.8 cm) and
supports high- and low-profile brackets
Connection
ConnectionConnection
Connection
Single RJ-11 connector
Other Features
Other FeaturesOther Features
Other Features
Digital line protection, call progress monitoring via on-board piezo device,
support for high profile and low profile brackets, PnP ID support
Safety
SafetySafety
Safety
UL recognized to UL 1950, 3rd edition (U.S. and Canada); IEC 950 (TUV,
NEMKO, DEMKO, SEMKO); CE Mark, EC 950 (TUV, NEMKO, DEMKO,
SEMKO, CE mark
EMC
EMCEMC
EMC
FCC Part 15, IC ES003, EN 55022, 3rd edition, EN 55024, annex A, EN
61000-4-6, EN 61000-4-8
Telecom
TelecomTelecom
Telecom
FCC Part 68, IC-CS-03 (Canada); Worldwide PTT approvals
Not available in Korea or the Republic of South Africa.
Health
HealthHealth
Health
Bare PCB material compliant to 94V-0 or better (marked as such)
Other
OtherOther
Other
PC 2001 compliant, PCI version 2.3, WHQL approved; ACPI compliant
QuickSpecs
HP Compaq dx2200 Microtower Business PC
HP Compaq dx2200 Microtower Business PCHP Compaq dx2200 Microtower Business PC
HP Compaq dx2200 Microtower Business PC
Technical Specifications - Communications
DA - 12426 North America — Version 14 — August 16, 2006
Page 19
