Service Reference Guide 490778-001 2–9
Setup Utilities and Diagnostics Features
Integrated
Peripherals
On-Chip Serial ATA Only available when you enter to setup with
advanced mode(Ctrl+A). Allows user to
select a setting for the working mode of the
onboard SATA devices:
•Disabled
•Auto
• Combined Mode
• Enhanced Mode
•SATA Only
SATA PORT Speed Settings Only available when you enter to setup with
advanced mode(Ctrl+A). Allows you to
Show/Modify when On-Chip Serial ATA is
Enhanced Mode:
•Disabled
•Force GEN I
•Force GEN II
PATA IDE Mode Only available when you enter to setup with
advanced mode(Ctrl+A). Allows you to
Show/Modify when On-Chip Serial ATA is
Combined Mode:
•Primary
• Secondary
SATA Port Only available when you enter to setup with
advanced mode(Ctrl+A). Show Only,
controlled by PATA IDE Mode:
•P1,P3 is Secondary
• P0,P2 is Primary
Computer Setup (Continued)
Heading Option Description
✎
Support for specific Computer Setup options may vary depending on the hardware
configuration.
