A memory module can be installed in only one way. Match the notch
on the module with the tab on the memory socket.
6. Push the module down into the socket, ensuring that the module is
fully inserted and properly seated. Make sure the latches are in the
closed position .
7. Repeat steps 5 and 6 to install any additional modules.
8. Replace the access panel.
The computer should automatically recognize the additional memory
the next time you turn on the computer.
Hardware Reference Guide www.hp.com/in 2-7
Hardware Upgrades
5. Open both latches of the memory module socket , and insert the
memory module into the socket
1
3
2
Installing a DIMM
Photos depicted may vary as per actual machine
