Product Features
Rear Panel Components
Rear Panel Components
Power Cord Connector RJ-45 Network Connector .
Voltage Select Switch Parallel Port Connector
PS/2 Mouse Connector Monitor Connector
PS/2 Keyboard Connector Headphone/Line-Out Connector
Universal Serial Bus (USB) Audio/Line-In Connector
Serial Port Connector Microphone Connector
1 7
2 8
3 9
4 10
5
11
6
12
Arrangement and number of connectors may vary by model.
!
Photos depicted may vary as per actual machine
