Broadcom NetXtreme
Gigabit Ethernet LAN on
Motherboard
(LOM)
Connector
RJ-45
Controller
Broadcom 5751 PCI-Express LAN Controller
Memory
Integrated 72KByte frame buffer memory
Network data rates
supported
10Mbps-Half Duplex, 10Mbps-Full Duplex/100Mbps-Half Duplex, 100Mbps
Full Duplex /1000Mbps
Compliance
IEEE 802.1A, 802.1P, 802.1P, 802.1Q, 802.2, 802.3, 802.3AB and 802.3u
compliant, 802.3x flow control
Bus architecture
PCI-Express 1.0a
Data path width
x1
Data transfer mode
Bus-master DMA
Hardware certifications
FCC, B, CE, TUV- cTUVus Mark Canada and United States, TUV- GS Mark for
European Union
Power requirement
1.45 watts maximum
Boot ROM support
Yes
LEDs
2; #1 on for link and flashes off for activity; #2 green for 1000Mbps, yellow
for 100Mbps, off for 10Mbps
Auto MDI-X
Automatic MDI crossover is supported (eliminates need for crossover cables)
Statistics
SNMP MIB II, Ethernet-like MIB, and Ethernet MIB (802.3z Clause 30)
Teaming
Supported (additional NICs required)
Package
196-pin BGA
Environmental
Operating temperature
32° to 131°F (0° to 55° C)
Operating humidity
85% at 131° F (55° C)
Dimensions
0.59 x 0.59 in (15 x 15 mm)
Management capabilities
ACPI, WoL and DMI 2.0, PXE 2.0, WfM 2.0, Broadcom mgmt utility
Alerting
ASF 1.1
Intel PRO/1000 GT Gigabit
PCI NIC
Connector
RJ-45
Controller
Intel 82541PI Gigabit Controller
Memory
Integrated 64KB configurable transmit receive buffer memory
Data rates supported
10/100/1000 Mbps
Compliance
IEEE 802.1P, 802.1Q, 802.2, 802.3, 802.3AB and 802.3u compliant, 802.3x
flow control
Bus architecture
PCI 2.3
Data path width
32-bit, 33/66 MHz bus interface
Data transfer mode
Bus-master DMA
Hardware certifications
FCC, B, CE, TUV- cTUVus Mark Canada and United States, TUV- GS Mark for
European Union
Power requirement
(800mA) 4watts @ +5VDC
Boot ROM support
Yes
QuickSpecs
HP dx5150 Business PC
Technical Specifications - Communications
DA - 12105 North America — Version 26 — July 10, 2007
Page 30
