HP EliteBook 2540P Specifications

Chipset
ChipsetChipset
Chipset Mobile Intel QM57 Express Chipset
Intel Core i5 with
Intel Core i5 withIntel Core i5 with
Intel Core i5 with
vPro/Core i7 with vPro
vPro/Core i7 with vProvPro/Core i7 with vPro
vPro/Core i7 with vPro
technology capable
technology capabletechnology capable
technology capable
Intel Core i5 with vPro and Core i7 with vPro technology is a selectable feature that is available on units
configured with an Intel Centrino® Advanced-N 6200 series WLAN module and a preinstalled Windows
operating system. It provides advances in remote manageability, security, energy efficient performance,
and wireless connectivity. Intel Active Management Technology (AMT) offers built-in manageability and
proactive security for networked notebook PCs, even when they are powered off* or when the operating
system is inoperable. It can help identify threats before they reach the network, isolate infected systems,
and update PCs regardless of their power state.
*Requires a Windows operating system, network hardware and software, connection with a power
source, and a direct (non-VPN) corporate network connection which is either cable or wireless LAN.
NOTE:
NOTE:NOTE:
NOTE: Some functionality of Intel Core i5 with vPro/Core i7 with vPro technology, such as Intel Active
Management technology and Intel Virtualization technology, requires additional 3rd party software in
order to run. Availability of future "virtual appliances" applications for Intel Core i5 with vPro/Core i7
with vPro technology is dependent on 3rd party software providers. Compatibility with future "virtual
appliances" is yet to be determined.
Graphics
GraphicsGraphics
Graphics Intel HD Graphics with dynamic frequency
Microsoft DirectX 10.1 (Shader Model 4.1)
Display
DisplayDisplay
Display Internal
InternalInternal
Internal 12.1-inch diagonal LED-backlit WXGA anti-glare (1280 x 800)
Ambient Light Sensor
Optional HP Privacy Filter
External
ExternalExternal
External Up to 32-bit per pixel color depth
DisplayPort
DisplayPortDisplayPort
DisplayPort supports resolutions up to 2560 x 1600, 30-bit color depth at
60 Hz, and full HD (1920 x 1080) monitors, 24-bit color depth at 120 Hz
VGA
VGAVGA
VGA port supports resolutions up to 2048 x 1536 at 75 Hz, and lower
resolutions at up to 100 Hz
NOTE:
NOTE:NOTE:
NOTE: Resolutions are dependent upon monitor capability, and resolution
and color depth settings.
Memory
MemoryMemory
Memory Standard
StandardStandard
Standard DDR3 PC3-10600 SDRAM (1333 MHz) *
Two SODIMM slots supporting dual-channel memory
1024 MB, 2048 MB and 4096 MB SODIMMs
Maximum
MaximumMaximum
Maximum Upgradeable to 8192 MB with 4096 MB SODIMMs in slots 1 and 2
Dual-channel
Dual-channelDual-channel
Dual-channel Maximized dual-channel performance requires SODIMMs of the same size
and speed in both memory channels.
* Memory bus runs at a maximum of 1066 MHz.
NOTE:
NOTE:NOTE:
NOTE: Due to the non-industry standard nature of some third-party memory modules, we recommend
HP branded memory to ensure compatibility. If you mix memory speeds, the system will perform at the
lower memory speed. Full availability of 4 GB or more of memory requires a Windows 64-bit operating
system or Linux. With Windows 32-bit operating systems, the amount of usable memory is dependent
upon your configuration, so that above 3 GB all memory may not be available due to system resource
requirements.
QuickSpecs
HP EliteBook 2540p Notebook PC
HP EliteBook 2540p Notebook PCHP EliteBook 2540p Notebook PC
HP EliteBook 2540p Notebook PC
Standard Features (availability may vary by country)
DA - 13566 North America — Version 8 — June 2, 2010 Page 6

HP EliteBook 2540P Specifications

General

Bus type	DMI
Stepping	C2
Tjunction	105 °C
Processor cache	4 MB
Processor cores	2
Processor model	i7-640LM
System bus rate	2.5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-600 Mobile Series
Processor socket	BGA 1288
Processor threads	4
Processor codename	Arrandale
Processing Die size	81 mm²
Processor frequency	2.13 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	2.93 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16
Thermal Design Power (TDP)	25 W
Maximum number of PCI Express lanes	16
Number of Processing Die Transistors	382 M
Motherboard chipset	Intel® QM57 Express
HDD speed	5400 RPM
HDD interface	SATA
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Total storage capacity	250 GB
Display diagonal	12.1 \
Display resolution	1280 x 800 pixels
Native aspect ratio	16:10
Memory slots	2x SO-DIMM
Internal memory	2 GB
Internal memory type	DDR3-SDRAM
Maximum internal memory	- GB
Memory layout (slots x size)	1 x 2 GB
Discrete graphics card model	-
On-board graphics card model	Intel® HD Graphics
On-board graphics card base frequency	266 MHz
On-board graphics card dynamic frequency (max)	566 MHz
Type	PC
Intel segment tagging	Enterprise
Bluetooth version	2.1+EDR
Operating system installed	Windows XP Professional
Number of battery cells	6
Charging port type	DC-in jack
Serial ports quantity	0
USB 2.0 ports quantity	3
Cable lock slot type	Kensington
Product color	Black
Country of origin	China
Pointing device	Touchpad
Processor code	SLBMK
Processor ARK ID	43563
Processor package size	BGA 34 x 28 mm
Graphics & IMC lithography	45 nm
Supported instruction sets	SSE4.1, SSE4.2
Intel® Turbo Boost Technology	1.0

Weight and Dimensions

Depth	210 mm
Width	280 mm
Weight	1530 g
Height (front)	30 mm
