HP EliteBook 2560p

HP 65W Smart AC Adapter Dimensions 4.17 x 1.85 x 1.1 in (10.6 x 4.7 x 2.8 cm)
Weight 0.62 lb (280 g)
Input 100 to 240 VAC
Input Efficiency 87% min at 115 VAC
Input frequency range 47 to 63 Hz
Input AC current 1.7 A at 90 VAC, 0.85 A at 180 VAC
Output Output power 65W
DC output 18.5V
Hold-up time 5 msec at 115 VAC input
Output current limit <11A, Over voltage protection- 29V max
automatic shutdown
Connector 3 pin/grounded, mates with interchangeable cords
Environmental Design Operating temperature 32° to 104° F (0° to 40° C)
Non-operating (storage)
temperature
-4° to 149° F (-20° to 65° C)
Altitude 0 to 10,000 ft (0 to 3,048 m)
Humidity 20% to 80%
Storage Humidity 10% to 90%
EMI and Safety
Certifications
CE Mark - full compliance with LVD and EMC directives; Worldwide safety
standards - IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals -
C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B,
CCC, NOM-1 NYCE; MTBF - over 200,000 hours at 25°C ambient condition.
3-cell 31 WHr Li-Ion
Battery
SX03031
Dimensions (H x W x L) 0.8 x 1.2 x 8.1 in (2 x 3 x 20.5 cm)
Weight (max) 0.37 lb (0.166 kg)
Cells/Type Lithium-Ion
Energy Voltage 11.1V
Amp-hour capacity 2.8Ah
Watt-hour capacity 31Wh
Temperature Operating (Charging) 32° to 113° F (0° to 45° C)
Operating (Discharging) 14° to 122° F(-10° to 50° C)
Non-operating -4° to 122° F (-20° to 50° C)
Battery Re-Charge Time System in OFF or Standby
Mode
2.5 hours
System ON 3 to 5 hours
Fuel Gauge LED No
Warranty 1 year
Optional Travel Battery
Available
No
QuickSpecs
HP EliteBook 2560p Notebook PC
Technical Specifications
DA - 14001 Worldwide — Version 10 — August 3, 2012 Page 17
