HP EliteBook 2560p Specifications

At A Glance
At A GlanceAt A Glance
At A Glance
Genuine Windows® 7 versions or FreeDOS
12.5-inch diagonal LED-backlit HD display, ambient light sensor
Industrial, business rugged HP DuraCase construction features a full magnesium alloy chassis, wear-resistant HP DuraFinish,
precision aluminum-alloy hinges, and cast titanium-alloy display latches; designed to meet the military standard Mil-Std-810G
for vibration, dust, altitude, and high temperature operation *
Spill-resistant keyboard with drains
Choice of an Intel® Core™ i7 or Core i5 standard voltage processor for maximum performance
Intel vPro technology (optional) enables you to remotely monitor, diagnose, and repair PCs over the network, even if a system's
OS is inoperable or it is powered off
Optional fixed optical drive or weight saver
Choice of 7200 rpm 2.5-inch hard drive up to 500 GB, with HP 3D DriveGuard protection; or 128/160 GB Solid State Drive
Flexible wireless connectivity options:
Integrated HP hs2340 HSPA+ Mobile Broadband module connects to both HSPA and HSPA+ (UMTS) networks and
provides GPS functionality
Integrated HP un2430 EV-DO/HSPA Mobile Broadband module (Gobi 3000) provides GPS functionality
(availability expected May, 2011)
Integrated Intel® Centrino® 802.11 a/b/g/n 2x2 or a/b/g/n 3x3, or Broadcom 802.11 a/b/g/n 2x2 or b/g/n 1x1
wireless LAN module
Bluetooth v2.1+EDR
Choice of 9-cell or 6-cell battery, including HP Long Life battery, to customize weight, run-time, and battery life to your needs
HP Power Assistant to conserve power, increase battery run-time, monitor power needs, and report workforce power
consumption
Integrated Intel HD Graphics 3000
SRS Premium Sound optimized for high fidelity audio
Security features including HP ProtectTools, with central management across HP and non-HP client PCs
Separate launch buttons for easy access to the following features: wireless on/off, HP QuickWeb, and volume mute
HP DayStarter for display of calendar information during Windows startup
DisplayPort for high resolution support
Optional HP 2560 Series Docking Station provides additional DisplayPort, eSATA port, four additional USB ports (one
charging), audio in/out ports, RJ-45, VGA, power connector, and HP Docking Station Cable Lock
Optional HD Webcam
Dual pointing devices (touchpad with scroll zone and pointstick)
HP Night Light
ExpressCard/34 slot
Secure Digital/MMC slot
BFR/PVC-free**, ENERGY STAR qualified and EPEAT Gold Target registered in the U.S. EPEAT status varies by country- please
see epeat.net.
* Testing was not intended to demonstrate fitness for DOD contracts requirements or for military use. Test results are not a guarantee
of future performance under these test conditions.
** Meeting the industry definition of 'BFR/PVC-free' per the iNEMI Position Statement on "Low Halogen" Electronics. Plastic parts
incorporated into the chassis generally contain < 1000 ppm (0.1%) of bromine or chlorine. Printed circuit board and substrate
laminates generally contain < 1500 ppm (0.15%) of total bromine and chlorine. Service parts after purchase may not be BFR/PVC-
free. External accessories, including power supplies, power cords, and peripherals as well as the following customer-configurable
internal components: ATT SIM card are not BFR/PVC-free.
QuickSpecs
HP EliteBook 2560p Notebook PC
HP EliteBook 2560p Notebook PCHP EliteBook 2560p Notebook PC
HP EliteBook 2560p Notebook PC
Overview
DA - 14001 North America — Version 5 — July 12, 2011 Page 3

HP EliteBook 2560p Specifications

General

Bus type	DMI
Stepping	J1
Tjunction	100 C °C
Processor cache	4 MB
Processor cores	2
Processor model	i7-2640M
System bus rate	5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-2600 Mobile Series
Processor socket	-
Processor threads	4
Processor codename	Sandy Bridge
Processor frequency	2.8 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.5 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	28
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel® QM67 Express
HDD speed	7200 RPM
HDD interface	SATA II
Storage media	HDD
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Total storage capacity	320 GB
Compatible memory cards	MMC, SD
Number of HDDs installed	1
Display diagonal	12.5 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	16 GB
Type	PC
Intel segment tagging	Enterprise
On-board graphics card ID	0x116
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1300 MHz
Audio system	SRS PS
Pointing device	Touchpad + Pointing Stick
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
Cabling technology	10/100/1000Base-T(X)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Networking features	Gigabit Ethernet
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Trial software	Norton Internet Security 2011
Operating system installed	Windows 7 Professional
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Battery capacity	55 Wh
Battery life (max)	8.5 h
Number of battery cells	6
AC adapter power	65 W
Operating temperature (T-T)	5 - 35 °C
Sustainability certificates	ENERGY STAR
Processor code	SR03R
Processor ARK ID	53464
Processor package size	37.5 x 37.5 (rPGA988B); 31 x 24 (BGA1023) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00
Country of origin	China

Weight and Dimensions

Depth	209 mm
Width	305.2 mm
Height	27.4 mm
Weight	1670 g
