HP EliteBook 2570p Technical White Paper

Page 5
Hard Drive (HDD) & Solid State Drive (SSD) Diagnostics
HP Diagnostics
In the event you experience hard or solid state drive issues, the first step is to select the f2 function key
when booting up the system. This diagnostic routine detects any faults and issues that can cause the
drive to fail.
Note: The short/Basic and long/Full versions have been combined into one.
When initiated, the diagnostics perform the following steps:
 Runs the short/basic test. If no errors occur, the long/full test automatically runs.
 If no errors occur, S.M.A.R.T. attribute checking automatically runs.
 If a fault is detected in either of the tests, the process halts and a Failure ID or Code is displayed.
Note: The diagnostics may be aborted at any time by pressing the Esc key.
Note: The f2 Self-Test is available through the commercial notebook system BIOS. Please visit the HP
Web site at
http://welcome.hp.com/country/us/en/support.html to download the latest BIOS for your
product. See the UEFI section below to install the more advanced diagnostics.
Advanced Diagnostics – Unified Extensible Firmware Interface (UEFI)
The HP System Diagnostics UEFI or HP UEFI Support Environment downloads provide more advanced
diagnostic tests, which can be installed to a USB key. Go to your product Software & Drivers
download page to obtain:
http://welcome.hp.com/country/us/en/support.html
To launch the UEFI diagnostics, select the f2 function key when booting up the system.
Note: The diagnostics may be aborted at any time by pressing the Esc key.
Additional information can be found at the following URL:
http://h20000.www2.hp.com/bizsupport/TechSupport/Document.jsp?lang=en&cc=us&objectID=c01443317&
jumpid=reg_R1002_USEN
HP 3D Drive Guard
The opportunity for operational shock is greatest when the notebook is being moved. If the notebook
is accidentally dropped or is abruptly impacted by another object, the HP 3D Drive Guard driver
receives notifications from the integrated accelerometer, and protects the hard drive (HDD) by
automatically "parking the heads" to reduce the risk of damage.
Download the latest HP 3D Drive Guard driver under the Solutions section from the “Download
Drivers & Software” website for your product and OS:
http://www8.hp.com/us/en/support-drivers.html
Note: The 3D Drive Guard is not needed for SSD drives, but it does not harm or in any way damage
an SSD if installed.
Firmware & Product Updates
It is important to check for updates for your product. There are new firmware updates for certain OEM
drives and/or special product updates
. Download and install any newer HDD firmware updates or
other HDD related product drivers for your product and OS:
http://www8.hp.com/us/en/support-drivers.html

HP EliteBook 2570p Specifications

General

Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1600 MHz
Memory form factor	SO-DIMM
Internal memory type	DDR3-SDRAM
Maximum internal memory	- GB
LED backlight	Yes
Display diagonal	12.5 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Bus type	DMI
Stepping	L1
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
Processor model	i5-3210M
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-3200 Mobile series
Processor socket	BGA 1023
Processor threads	4
Processor codename	Ivy Bridge
Processor frequency	2.5 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.1 GHz
Processor operating modes	64-bit
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	25
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel® QM77 Express
HDD speed	7200 RPM
HDD interface	SATA II
Storage media	HDD
Optical drive type	DVD Super Multi DL
Total storage capacity	500 GB
Compatible memory cards	SD
Number of HDDs installed	1
On-board graphics card ID	0x166
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 4000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1100 MHz
Intel segment tagging	Enterprise
Audio system	SRS Pro
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Cabling technology	10/100/1000Base-T(X)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
eSATA/USB 3.2 Gen 1 (3.1 Gen 1) ports quantity	0
Keyboard layout	-
Pointing device	Touchpad
Operating system installed	Windows 8 Pro
Form factor	Clamshell
Product type	Laptop
Product color	Gray
Country of origin	China
Battery capacity	55 Wh
Battery life (max)	- h
Number of battery cells	6
AC adapter power	65 W
Sustainability certificates	ENERGY STAR
Processor code	SR0N0
Processor ARK ID	65708
Processor package size	31.0 x 24.0 (BGA1023) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	209 mm
Width	305 mm
Height	27 mm
Weight	1630 g
