HP EliteBook 8530p Quickspecs

1. Memory module and WLAN compartment 5. Battery bay
2. Hard drive bay 6. Battery release latch
3. Business card holder 7. Docking connector
4. Secondary battery connector
NOTE: WWAN module compartment is accessible under the keyboard.
At A Glance
Genuine Windows Vista Business 64 (supported, not preinstalled), Genuine Windows Vista Business 32, Genuine Windows Vista
Business with downgrade to Windows XP Professional custom installed, or FreeDOS
ATI Mobility Radeon HD 3650 graphics with up to 256 MB dedicated memory
DirectX 10 support and Dual Link DVI (available through optional docking) provides faster rendering capabilities and support for
ultra-high resolution monitors
Intel® Centrino® 2 with vPro™ technology capable, with Intel Core™2 Duo processors
Designed to travel, with weight starting at 6.3 lb/2.86 kg and 1.1-inch/28.2 mm thin at front
Business Rugged - designed to meet the military standard Mil-Std-810F for shock, vibration, sand and dust, humidity, altitude,
and high temperature operation *
Flexible wireless connectivity options:
Integrated HP un2400 EV-DO/HSDPA Mobile Broadband Module provides worldwide Gobi mobile Internet technology
Integrated 802.11 a/b/g/draft-n wireless LAN module
Bluetooth®
HDMI high definition video/audio port
eSATA connector for external optical drive, hard drive, or RAID array
Upgrade Bay for easy optical drive upgrade or optional second hard drive for RAID 1 Mirroring or RAID 0 Striping
Optional Blu-Ray DVD+/-RW SuperMulti DL Drive
QuickSpecs
HP EliteBook 8530p Notebook PC
Overview
DA - 13094 North America — Version 14 — September 18, 2009 Page 3

HP EliteBook 8530p Specifications

General

Bus type	FSB
Stepping	E0
Tjunction	105 °C
Processor cache	6 MB
Processor cores	2
Processor model	T9400
System bus rate	- GT/s
Processor family	Intel® Core™2 Duo
Processor series	Intel Core 2 Duo T9000 Series
Processor socket	Socket 479
Processor codename	Penryn
Processing Die size	107 mm²
Processor frequency	2.53 GHz
Processor cache type	L2
Processor technology	Intel Centrino 2 w/ vPro
Processor lithography	45 nm
Processor manufacturer	Intel
Processor front side bus	1066 MHz
Processor operating modes	64-bit
ECC supported by processor	No
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	9.5
Number of Processing Die Transistors	410 M
Motherboard chipset	Intel® PM45 Express
HDD speed	7200 RPM
HDD interface	SATA II
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Total storage capacity	250 GB
Display surface	Matt
Display diagonal	15.4 \
Display resolution	1680 x 1050 pixels
Native aspect ratio	16:10
Type	PC
Minimum RAM	1000 MB
Modem speed	56 Kbit/s
Battery type	8-cell (73 WHr) Lithium-Ion
Expansion slots	1 Express Card/54; 1 media card reader
Rear ports note	1 external VGA monitor; 1 AC power
Size (imperial)	14 \
Power management	8-cell (73 WHr) Lithium-Ion battery, optional HP (52 WHr) Extended Life Battery, optional HP (95 WHr) Ultra-Capacity Battery
Power supply type	External 120-watt Smart AC adapter; HP Fast Charge
Weight (imperial)	Weight varies by configuration and component. Starting at 6.3 lb lbs
Dimensions (WxDxH)	355 x 263.5 x 28.2 mm
Wireless technology	802.11a/b/g/n
Manageability features	HP 3D DriveGuard
Compatible operating systems	Genuine Windows Vista Business 64; Genuine Windows Vista Enterprise
Memory slots	2x SO-DIMM
Internal memory	2 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	8 GB
Discrete graphics card model	AMD Mobility Radeon HD 3650
Maximum graphics card memory	0.256 GB
Discrete graphics card memory	0.25 GB
Audio system	HD Audio
Audio included	High Definition Audio, stereo speakers, stereo headphone/line out, stereo microphone in, integrated dual-microphone array
Bluetooth version	2.0+EDR
Networking features	Gigabit Ethernet, WLAN
Bundled software	HP Recovery Manager, HP Client Manager Software, HP Client Configuration Management Agent, HP OpenView PC Configuration Management Solutions
Operating system installed	Windows Vista Business
Optional operating system supplied	Windows XP Professional
Number of battery cells	8
I/O ports	4 USB 2.0; 1 1394a; 1 RJ-11; 1 RJ-45; 1 microphone in; 1 headphone/line-out; 1 docking connector; 1 HDMI; 1 battery connector; 1 eSATA
Charging port type	DC-in jack
Serial ports quantity	0
USB 2.0 ports quantity	4
AC adapter power	120 W
Keyboard type	101/102-key compatible keyboard with HP DuraKeys
Pointing device	Touchpad + Scroll zone
Certification	ENERGY STAR qualified
Storage drive type	250 GB 7200 rpm SATA II
Video card features	ATI Mobility RadeonTM HD 3650
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Non-operating relative humidity (non-condensing)	5 - 90 %
Processor code	SLGEK
Processor ARK ID	35562
Processor package size	35 x 35 mm
Country of origin	China

Weight and Dimensions

Depth	263.5 mm
Width	355 mm
Weight	2860 g
Height (front)	28.2 mm
