HP EliteBook 8540P Specification

HP Integrated Module
with Bluetooth
Wireless Technology
Bluetooth Specification v2.1 compliant
Works with a wide range of Bluetooth devices
* In countries where 802.11n is not allowed, this capability is not enabled (802.11a/b/g only).
Keyboard The HP spill-resistant keyboard is designed using a thin layer of Mylar film under the keyboard
and a drain system that funnels fluid through a hole in the bottom of the notebook. This minimizes
the risk of damage to sensitive components underneath. The 101/102-key compatible keyboard
features an industry standard, full-pitch key layout with desktop keyboard features, such as the
isolated inverted-T cursor control keys, editing keys, both left and right control and alt keys, and
12 function keys. U.S. and International key layouts are available. Includes a full numeric keypad,
hotkeys for instant access to power conservation, brightness, and other features. It has 19.05 x
19.05 mm key pitch (center-to-center spacing) and 2.5 mm stroke.
HP DuraKeys is a clear coating applied over the notebook keyboard that helps protect the finish
and the printed characters on the keys. HP DuraFinish helps protect the finish on the keyboard
deck, graphics, and icons from normal wear and tear.
Touch-sensitive
controls
Touch-sensitive controls provide easy access to the following features: HP QuickLook 3, HP
QuickWeb, wireless on/off, touchpad on/off, volume mute, volume down, volume up, and
calculator button.
Dual Pointing devices Touchpad with scroll zone, three pick buttons
Pointstick with three additional pointstick buttons
Expansion card slots ExpressCard/54 slot Supports ExpressCard/54
Integrated Smart Card
Reader
Compatible with ISO 7816 compliant Smart Cards
PC/SC interface support
Secure Digital slot Supports SD (Secure Digital), MMC (MultiMedia Card), Memory Stick,
Memory Stick Pro, Memory Stick Duo * , xD-Picture card
* Memory Stick Duo Adapters are required and sold separately. Inserting a Memory Stick Duo
Card directly into your notebook could damage the memory card and/or notebook.
Internal Storage Hard Drives 250/320/500 GB 7200 rpm SMART SATA II
NOTE: These hard drives are customer removable and will withstand multiple insertion/removal
cycles. Up to 10 GB is reserved for the system recovery software.
HP 3D DriveGuard
(Windows only)
The hard drive is mounted directly to the notebook frame, reducing the
transmission of shock to the hard drive. Uses three-axis digital motion
detection with intelligent sensitivity to help protect the hard drive during
normal use from shock and vibration. The digital accelerometer
temporarily halts all data transfer and parks the hard drive when abrupt
motion is detected.
Solid State Drives 160 GB Solid State Drive
256 GB Solid State Drive
QuickSpecs
HP EliteBook 8540p Notebook PC
Standard Features
DA - 13521 Worldwide QuickSpecs — Version 7 — 3.1.2010 Page 8

HP EliteBook 8540P Specifications

General

Bus type	DMI
Stepping	K0
Tjunction	105 °C
Processor cache	4 MB
Processor cores	2
Processor model	i7-640M
System bus rate	2.5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-600 Mobile Series
Processor socket	BGA 1288
Processor threads	4
Processor codename	Arrandale
Processing Die size	81 mm²
Processor frequency	2.8 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
PCI Express slots version	2.0
Processor boost frequency	3.46 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	21
Maximum number of PCI Express lanes	16
Number of Processing Die Transistors	382 M
Motherboard chipset	Intel® QM57 Express
HDD speed	7200 RPM
HDD interface	SATA
Optical drive type	-
Card reader integrated	Yes
Total storage capacity	320 GB
Number of HDDs installed	1
Display diagonal	15.6 \
Display resolution	1600 x 900 pixels
Native aspect ratio	16:9
Modem speed	56 Kbit/s
Power supply type	AC/DC
Intel segment tagging	Enterprise
Compliance industry standards	IEEE802.3, IEEE802.3u, IEEE802.3ab
Internal memory	4 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	8 GB
On-board graphics card model	Intel® HD Graphics
On-board graphics card base frequency	500 MHz
On-board graphics card dynamic frequency (max)	766 MHz
Pointing device	Touchpad
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
Operating system installed	Windows 7 Professional
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
CardBus PCMCIA slots quantity	0
AC adapter power	90 W
Battery capacity	73 Wh
Number of battery cells	8
Product color	Black, Silver
Country of origin	China
Processor code	SLBTN
Processor ARK ID	49666
Processor package size	rPGA 37.5x 37.5, BGA 34x28 mm
Graphics & IMC lithography	45 nm
Supported instruction sets	SSE4.1/4.2
Intel® Turbo Boost Technology	1.0
Physical Address Extension (PAE)	36 bit

Weight and Dimensions

Depth	252 mm
Width	374 mm
Height	32 mm
Weight	2950 g
