HP EliteBook 8540P User Manual

HP Recovery Manager
HP Recovery ManagerHP Recovery Manager
HP Recovery Manager Models shipped with Windows 7 or Windows Vista include HP Recovery Manager. HP Recovery
Manager enables fast recovery of the factory preinstalled image if the system becomes corrupted or if
important system files are accidentally deleted. Up to 15 GB of the hard drive is reserved for the system
recovery software.
Security
SecuritySecurity
Security Standard Features
Standard FeaturesStandard Features
Standard Features HP ProtectTools Security Manager
Enhanced Pre-Boot Security
HP SpareKey
One-Step Logon
Setup Password
DriveLock Password
TPM 1.2 Embedded Security Chip *
TPM Enhanced DriveLock *
HP Disk Sanitizer
Kensington Lock slot
Support for Computrace ** LoJack Pro for HP ProtectTools
Optional Features
Optional FeaturesOptional Features
Optional Features HP Fingerprint Sensor
HP Fingerprint SensorHP Fingerprint Sensor
HP Fingerprint Sensor Enhanced sensor scans the fingerprint to uniquely
identify and authenticate a person.
HP Privacy Filter
HP Privacy FilterHP Privacy Filter
HP Privacy Filter Narrows viewing area so that screen data is
visible only to persons directly in front of the
monitor.
Computrace
ComputraceComputrace
Computrace ** LoJack Pro
LoJack Pro LoJack Pro
LoJack Pro
Premium for HP
Premium for HPPremium for HP
Premium for HP
ProtectTools with GPS
ProtectTools with GPSProtectTools with GPS
ProtectTools with GPS
Tracking
TrackingTracking
Tracking
Subscription based security solution providing the
ability to track, initiate physical recovery, conduct
asset management, and perform remote data
delete by utilizing GPS technology. GPS
functionality requires HP un2420 EV-DO/HSPA
Mobile Broadband Module.
* TPM module disabled where use is restricted by law; for example, Russia and China.
** The Computrace agent is shipped turned off, and must be activated by customers when they purchase
a subscription with terms ranging from one to five years.
For more information on HP security solutions refer to: http://www.hp.com/go/security .
HP ProtectTools Security
HP ProtectTools SecurityHP ProtectTools Security
HP ProtectTools Security
Manager
ManagerManager
Manager
HP ProtectTools Security Manager is the security platform for business notebooks and desktops. The HP
ProtectTools Security Manager is an extensible client security console that delivers enhanced security
capabilities through add-on software modules. The following modules are available on the hard drive
(also downloadable from the web) and can be configured in Software Setup:
Credential Manager for HP ProtectTools
Device Access Manager for HP ProtectTools
Drive Encryption for HP ProtectTools
File Sanitizer for HP ProtectTools
Privacy Manager for HP ProtectTools (Chat & Sign)
Embedded Security for HP ProtectTools
Computrace LoJack Pro for HP ProtectTools
QuickSpecs
HP EliteBook 8540p Notebook PC
HP EliteBook 8540p Notebook PCHP EliteBook 8540p Notebook PC
HP EliteBook 8540p Notebook PC
Standard Features
DA - 13521 North America — Version 13 — October 8, 2010 Page 11

HP EliteBook 8540P Specifications

General

Bus type	DMI
Stepping	K0
Tjunction	105 °C
Processor cache	4 MB
Processor cores	2
Processor model	i7-640M
System bus rate	2.5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-600 Mobile Series
Processor socket	BGA 1288
Processor threads	4
Processor codename	Arrandale
Processing Die size	81 mm²
Processor frequency	2.8 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
PCI Express slots version	2.0
Processor boost frequency	3.46 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	21
Maximum number of PCI Express lanes	16
Number of Processing Die Transistors	382 M
Motherboard chipset	Intel® QM57 Express
HDD speed	7200 RPM
HDD interface	SATA
Optical drive type	-
Card reader integrated	Yes
Total storage capacity	320 GB
Number of HDDs installed	1
Display diagonal	15.6 \
Display resolution	1600 x 900 pixels
Native aspect ratio	16:9
Modem speed	56 Kbit/s
Power supply type	AC/DC
Intel segment tagging	Enterprise
Compliance industry standards	IEEE802.3, IEEE802.3u, IEEE802.3ab
Internal memory	4 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	8 GB
On-board graphics card model	Intel® HD Graphics
On-board graphics card base frequency	500 MHz
On-board graphics card dynamic frequency (max)	766 MHz
Pointing device	Touchpad
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
Operating system installed	Windows 7 Professional
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
CardBus PCMCIA slots quantity	0
AC adapter power	90 W
Battery capacity	73 Wh
Number of battery cells	8
Product color	Black, Silver
Country of origin	China
Processor code	SLBTN
Processor ARK ID	49666
Processor package size	rPGA 37.5x 37.5, BGA 34x28 mm
Graphics & IMC lithography	45 nm
Supported instruction sets	SSE4.1/4.2
Intel® Turbo Boost Technology	1.0
Physical Address Extension (PAE)	36 bit

Weight and Dimensions

Depth	252 mm
Width	374 mm
Height	32 mm
Weight	2950 g
