Page #21 background imageLoading...
Page #21 background image
Saudi Arabian
Compliance (ICCP)
Yes
SABS
Yes
UKRSERTCOMPUTER
Yes
* Configurations of the HP EliteBook 8540w that are ENERGY STAR qualified are identified as
HP EliteBook 8540w ENERGY STAR on HP websites and on
www.energystar.gov
.
** EPEAT TBD Registered in U.S. EPEAT registration varies by country. See
www.epeat.net
for registration
status by country.
NOTE:
NOTE:NOTE:
NOTE:
For accessibility information on HP products, please visit:
http://www.hp.com/accessibility
.
HP 150W Smart AC
HP 150W Smart ACHP 150W Smart AC
HP 150W Smart AC
Adapter
AdapterAdapter
Adapter
Dimensions
DimensionsDimensions
Dimensions
6.65 x 2.76 x 1.57 in (16.9 x 7.0 x 4.0 cm)
Weight
WeightWeight
Weight
1.54 lb (700 g)
Input
InputInput
Input
100 to 240 VAC
Input Efficiency
83% min at 115 VAC
Input frequency range
47 to 63 Hz
Input AC current
2.2 A at 90 VAC, 1.1 A at 180 VAC
Output
OutputOutput
Output
Output power
150W
DC Output Voltage
19.0V
Hold-up time
5 msec at 115 VAC input
Output current limit
<15A, Over voltage protection- 29V max
automatic shutdown
Connector
ConnectorConnector
Connector
3 pin/grounded, mates with interchangeable cords
Environmental Design
Environmental DesignEnvironmental Design
Environmental Design
Operating Temperature
32° to 104° F (0° to 35° C)
Non-operating (storage)
Temperature
-4° to 149° F (-20° to 65° C)
Altitude
0 to 10,000 ft (0 to 3,048 m)
Humidity
20% to 80%
Storage Humidity
10% to 90%
EMI and Safety
EMI and SafetyEMI and Safety
EMI and Safety
Certifications
CertificationsCertifications
Certifications
CE Mark- full compliance with LVD and EMC directives; Worldwide safety
standards- IEC950, EN60950, UL1950, Class 1, SELV; Agency approvals-
C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22
Class B, CCIB, NOM-1 NYCE; MTBF- over 200,000 hours at 25°C ambient
condition.
QuickSpecs
HP EliteBook 8540w Mobile Workstation
HP EliteBook 8540w Mobile WorkstationHP EliteBook 8540w Mobile Workstation
HP EliteBook 8540w Mobile Workstation
Technical Specifications
DA - 13529 Canada — Version 24 — September 29, 2011
Page 21

Other manuals for HP EliteBook 8540w

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP EliteBook 8540w and is the answer not in the manual?

HP EliteBook 8540w Specifications

General IconGeneral
Bus typeDMI
SteppingB1
Tjunction100 °C
Processor cache8 MB
Processor cores4
Processor modeli7-840QM
System bus rate2.5 GT/s
Processor familyIntel® Core™ i7
Processor seriesIntel Core i7-800 Mobile Series
Processor socketSocket 988
Processor threads8
Processor codenameClarksfield
Processing Die size296 mm²
Processor frequency1.86 GHz
Processor cache typeSmart Cache
Processor lithography45 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version2.0
Processor boost frequency3.2 GHz
Processor operating modes64-bit
ECC supported by processorNo
PCI Express configurations1x16, 2x8
Thermal Design Power (TDP)45 W
CPU multiplier (bus/core ratio)14
Maximum number of PCI Express lanes16
Number of Processing Die Transistors774 M
Motherboard chipsetIntel® QM57 Express
HDD speed7200 RPM
HDD interfaceSATA
Optical drive type-
Card reader integratedYes
Total storage capacity500 GB
Number of HDDs installed1
Display diagonal15.6 \
Native aspect ratio16:9
Modem speed56 Kbit/s
Power supply typeAC/DC
Intel segment taggingEnterprise
Compliance industry standardsIEEE802.3, IEEE802.3u, IEEE802.3ab
Internal memory4 GB
Memory clock speed1333 MHz
Internal memory typeDDR3-SDRAM
Maximum internal memory8 GB
Number of built-in speakers2
Pointing deviceTouchpad
Wi-Fi standards802.11a, 802.11b, 802.11g
Bluetooth version2.1+EDR
Cabling technology10/100/1000Base-T(X)
Networking featuresGigabit Ethernet
Operating system installedWindows 7 Professional
Charging port typeDC-in jack
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
CardBus PCMCIA slots quantity0
AC adapter power150 W
Battery capacity73 Wh
Product colorBlack, Silver
Country of originChina
Processor ARK ID43125
Processor package size37.5 x 37.5 mm
Supported instruction setsSSE4.2
Intel® Turbo Boost Technology1.0
Physical Address Extension (PAE)36 bit
Weight and Dimensions IconWeight and Dimensions
Depth251.5 mm
Width373.5 mm
Height32.4 mm
Weight2950 g
