HP EliteBook 8540w Specification

Intel Core i5 with
Intel Core i5 withIntel Core i5 with
Intel Core i5 with
vPro/Core i7 with vPro
vPro/Core i7 with vProvPro/Core i7 with vPro
vPro/Core i7 with vPro
technology capable
technology capabletechnology capable
technology capable
Intel Core i5 with vPro and Core i7 with vPro technology is a selectable feature that is available on units
configured with an Intel Centrino® Ultimate-N 6000 series WLAN module and a preinstalled Windows
operating system. It provides advances in remote manageability, security, energy efficient performance,
and wireless connectivity. Intel Active Management Technology (AMT) offers built-in manageability and
proactive security for networked notebook PCs, even when they are powered off* or when the operating
system is inoperable. It can help identify threats before they reach the network, isolate infected systems,
and update PCs regardless of their power state.
*Requires a Windows operating system, network hardware and software, connection with a power
source, and a direct (non-VPN) corporate network connection which is either cable or wireless LAN.
NOTE:
NOTE:NOTE:
NOTE: Some functionality of Intel Core i5 with vPro/Core i7 with vPro technology, such as Intel Active
Management technology and Intel Virtualization technology, requires additional 3rd party software in
order to run. Availability of future "virtual appliances" applications for Intel Core i5 with vPro/Core i7
with vPro technology is dependent on 3rd party software providers. Compatibility with future "virtual
appliances" is yet to be determined.
Graphics
GraphicsGraphics
Graphics ATI FirePro M5800 graphics with 1 GB dedicated DDR3 video memory
Microsoft DirectX 11 (Shader Model 4.1) and OpenGL 3.2 capable
NVIDIA Quadro FX 880M graphics with 1 GB dedicated DDR3 video memory
NVIDIA Quadro FX 1800M graphics with 1 GB dedicated GDDR5 video memory
Display
DisplayDisplay
Display Internal
InternalInternal
Internal 15.6-inch diagonal 16:9 LED-backlit HD+ anti-glare (1600 x 900
resolution)
15.6-inch diagonal 16:9 LED-backlit FHD anti-glare (1920 x 1080
resolution)
15.6-inch diagonal 16:9 LED-backlit FHD anti-glare DreamColor
(1920 x 1080 resolution)
Ambient Light Sensor
Optional HP Privacy Filter
External
ExternalExternal
External Up to 32-bit per pixel colour depth
DisplayPort
DisplayPortDisplayPort
DisplayPort supports resolutions up to 2560 x 1600, 30-bit colour depth at
60 Hz, and full HD (1920 x 1080) monitors, 24-bit colour depth at 120 Hz
VGA
VGAVGA
VGA port supports resolutions up to 2048 x 1536 at 75 Hz, and lower
resolutions at up to 100 Hz
DVI-D
DVI-DDVI-D
DVI-D (single link) video signal available through DVI port in optional HP
Docking Station (sold separately)
supports resolutions up to 1600 x 1200 at both full and reduced
blanking, and 1920 x 1200 at reduced blanking
NOTE:
NOTE:NOTE:
NOTE: Resolutions are dependent upon monitor capability, and resolution
and colour depth settings.
QuickSpecs
HP EliteBook 8540w Mobile Workstation
HP EliteBook 8540w Mobile WorkstationHP EliteBook 8540w Mobile Workstation
HP EliteBook 8540w Mobile Workstation
Standard Features
DA - 13529 Canada — Version 24 — September 29, 2011 Page 6

HP EliteBook 8540w Specifications

General

Bus type	DMI
Stepping	B1
Tjunction	100 °C
Processor cache	8 MB
Processor cores	4
Processor model	i7-840QM
System bus rate	2.5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-800 Mobile Series
Processor socket	Socket 988
Processor threads	8
Processor codename	Clarksfield
Processing Die size	296 mm²
Processor frequency	1.86 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.2 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8
Thermal Design Power (TDP)	45 W
CPU multiplier (bus/core ratio)	14
Maximum number of PCI Express lanes	16
Number of Processing Die Transistors	774 M
Motherboard chipset	Intel® QM57 Express
HDD speed	7200 RPM
HDD interface	SATA
Optical drive type	-
Card reader integrated	Yes
Total storage capacity	500 GB
Number of HDDs installed	1
Display diagonal	15.6 \
Native aspect ratio	16:9
Modem speed	56 Kbit/s
Power supply type	AC/DC
Intel segment tagging	Enterprise
Compliance industry standards	IEEE802.3, IEEE802.3u, IEEE802.3ab
Internal memory	4 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	8 GB
Number of built-in speakers	2
Pointing device	Touchpad
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
Operating system installed	Windows 7 Professional
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
CardBus PCMCIA slots quantity	0
AC adapter power	150 W
Battery capacity	73 Wh
Product color	Black, Silver
Country of origin	China
Processor ARK ID	43125
Processor package size	37.5 x 37.5 mm
Supported instruction sets	SSE4.2
Intel® Turbo Boost Technology	1.0
Physical Address Extension (PAE)	36 bit

Weight and Dimensions

Depth	251.5 mm
Width	373.5 mm
Height	32.4 mm
Weight	2950 g
