LED Activity
LED Off - Radio Off;
Solid LED On - Radio On
HP lt2522 LTE/EV-DO
Mobile Broadband Module
Technology/Operating
Bands
CDMA/1xRTT/EvDO: 800MHz (Cell), 1900MHz (PCS)
GSM/GPRS/EDGE: 850MHz (Cell), 900MHz (EGSM), 1800MHz (DCS), 1900MHz
(PCS)
UMTS/WCDMA with receive diversity: 2100MHz (UTRA FDD Band I), 1900MHz
(UTRA FDD Band II), 900MHz (UTRA FDD Band VIII), 850 MHz (UTRA FDD Band
V)
LTE: 700 MHz (Verizon, Band XIII)
Mobile Operator
Verizon (US only)
Wireless Protocol
Standards
GSM/GPRS/EDGE: Class B, Multi-slot class 10 operation, coding schemes CS1 -
CS4 and MSC1 - MSC9.
CDMA: 1xEVDO Release 0 and Release A, IS-95A, IS-95B, IS-856, IS-2000
UMTS/WCDMA: Release 99 and Release 7
LTE: Power Class III as per 3GPP TS 36.101
Wireless Parametric
Standards
Complies with 3GPP specifications Release 8 for LTE
Maximum Data Rates
EvDO (Revision A) - 3.1 Mbps (Download), 1.8 Mbps (Upload)
WCDMA (DC-HSPA+) - 42Mbps (Download)
LTE (Category 3) - 100 Mbps (Download ), 50Mbps (Upload)
GPS
Standalone, Assisted, XTRA
GPS Bands
1575.42 MHz (± 1.023 MHz)
Maximum Output Power
GSM/GPRS/EDGE: 32dBm (+/-1)
WCDMA: 24dBm (+0.7/-2.3)
LTE: +23 dBm (+2.7 dBm/-1.7 dBm)
1xRTT/EvDO: +24 dBm (+0.5 dBm/-1.5 dBm)
Maximum Power
Consumption
2700mA (peak)
Power Consumption,
Sleep Mode
10 mA
Power Management
USB selective suspend
Integrated notebook wireless button
Antenna Type
Dual high efficiency 6 band antennae with spatial diversity, mounted in the
display enclosure
Form Factor
PCI-Express MiniCard, USB 2.0 interface
Weight
< 10 g
Dimensions
(Length x
Width x Thickness)
2.01 x 1.18 x 0.18 in (51 x 30 x 4.5 mm)
Voltage, Operating
3.3v +/- 9%
Temperature, Operating
-4° to 149° F (-20° to 65° C)
Temperature, Non-
operating, 96 hours
(from
MIL-STD 202 Method 108)
-40° to 185° F (-40° to 85° C)
QuickSpecs
HP EliteBook 8470p Notebook PC
HP EliteBook 8570p Notebook PC
Technical Specifications
DA - 14304 North America — Version 16 — June 6, 2013
Page 29

Other manuals for HP EliteBook 8570p

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP EliteBook 8570p and is the answer not in the manual?

HP EliteBook 8570p Specifications

General IconGeneral
Bus typeDMI
SteppingL1
Tjunction105 °C
Processor cache3 MB
Processor cores2
Processor modeli5-3230M
System bus rate5 GT/s
Processor familyIntel® Core™ i5
Processor seriesIntel Core i5-3200 Mobile series
Processor socketBGA 1023
Processor threads4
Processor codenameIvy Bridge
Processor frequency2.6 GHz
Processor cache typeSmart Cache
Processor lithography22 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version3.0
Processor boost frequency3.2 GHz
Processor operating modes64-bit
ECC supported by processorNo
PCI Express configurations1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)35 W
CPU multiplier (bus/core ratio)26
Maximum number of PCI Express lanes16
Motherboard chipsetIntel® QM77 Express
Internal memory4 GB
Memory clock speed1600 MHz
Internal memory typeDDR3-SDRAM
Maximum internal memory- GB
HDD speed7200 RPM
HDD interfaceSATA
Storage mediaHDD
Optical drive typeDVD Super Multi
Card reader integratedYes
Total storage capacity500 GB
Number of HDDs installed1
Display diagonal15.6 \
Display resolution1366 x 768 pixels
Native aspect ratio16:9
On-board graphics card ID0x166
Discrete graphics card modelNot available
On-board graphics card modelIntel® HD Graphics 4000
On-board graphics card familyIntel® HD Graphics
On-board graphics card base frequency650 MHz
On-board graphics card dynamic frequency (max)1100 MHz
LightScribe-
Intel segment taggingEnterprise
Audio systemSRS PS PRO
WWANNot installed
Data networkNot supported
Wi-Fi standards802.11a, 802.11b, 802.11g
Bluetooth version4.0
Cabling technology10/100/1000Base-T(X)
Ethernet LAN data rates10, 100, 1000 Mbit/s
Charging port typeDC-in jack
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
eSATA/USB 3.2 Gen 1 (3.1 Gen 1) ports quantity0
Pointing deviceTouchpad
Operating system installedWindows 8 Pro
Form factorClamshell
Product typeLaptop
Product colorSilver
Country of originChina
Processor codeSR0WX
Processor ARK ID72056
Processor package size31 x 24 (BGA1023) mm
Supported instruction setsAVX
Intel Identity Protection Technology version1.00
Battery capacity62 Wh
Battery life (max)8.25 h
Number of battery cells6
AC adapter power65 W
AC adapter frequency50 - 60 Hz
AC adapter input voltage100 - 240 V
Sustainability certificatesEPEAT Gold, ENERGY STAR
Weight and Dimensions IconWeight and Dimensions
Depth251 mm
Width374 mm
Height34 mm
Weight2610 g
