HP EliteBook x360 1030 G2 Product End-Of-Life Disassembly Instructions

EL-MF877-00 Page 2
Template Revision B
PSG instructions for this template are available at EL-MF877-01
Components, parts and materials containing
refractory ceramic fibers
0
Components, parts and materials containing
radioactive substances
0
2.0 Tools Required
List the type and size of the tools that would typically be used to disassemble the product to a point where components
and materials requiring selective treatment can be removed.
Tool Description
Tool Size (if
applicable)
Screwdriver #1
Electric cross
screwdriver
Description #2
TORX T8
(2.31mm)
Description #3
D73 1 * 3.0 *
20 * 40
Description #4
Description #5
3.0 Product Disassembly Process
3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment:
1. Follow steps described in Disassembly instruction (file attached)
2. If parts can be removed without using a tool, remove it first
3. Use correct screwdriver and torque value before unlock the screw.
4.
5.
6.
7.
8.
9.
3.2 Optional Graphic. If the disassembly process is complex, insert a graphic illustration below to identify the items
contained in the product that require selective treatment (with descriptions and arrows identifying locations).

HP EliteBook x360 1030 G2 Specifications

General

Form factor	Convertible (Folder)
Product type	Laptop
Product color	Silver
Country of origin	China
Bus type	OPI
Stepping	H0
Tjunction	100 °C
Processor cache	3 MB
Processor cores	2
Processor model	i5-7200U
System bus rate	4 GT/s
Processor family	Intel® Core™ i5
Processor socket	BGA 1356
Processor threads	4
Processor codename	Kaby Lake
Configurable TDP-up	25 W
Processor frequency	2.5 GHz
Processor cache type	Smart Cache
Configurable TDP-down	7.5 W
Processor lithography	14 nm
Processor manufacturer	Intel
PCI Express slots version	3.0
Processor boost frequency	3.1 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x2+2x1, 1x4, 2x2, 4x1
Thermal Design Power (TDP)	15 W
Configurable TDP-up frequency	2.7 GHz
Configurable TDP-down frequency	0.8 GHz
Maximum number of PCI Express lanes	12
Pointing device	Touchpad
Spill-resistant keyboard	Yes
Internal memory	8 GB
Memory clock speed	2133 MHz
Internal memory type	DDR4-SDRAM
Maximum internal memory	16 GB
Memory layout (slots x size)	1 x 8 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	PCI Express
Storage media	SSD
SSD form factor	M.2
Total storage capacity	256 GB
Compatible memory cards	MicroSD (TransFlash)
Number of SSDs installed	1
Display diagonal	13.3 \
Native aspect ratio	16:9
On-board graphics card ID	0x5916
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 620
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	32 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	300 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1000 MHz
Battery capacity	57 Wh
Battery life (max)	16.5 h
Number of battery cells	3
AC adapter power	65 W
Front camera signal format	720p
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Mobile network generation	4G
HDMI version	1.4
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Sustainability certificates	ENERGY STAR
Processor code	SR2ZU
Processor ARK ID	95443
Processor package size	42 x 24 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Intel Identity Protection Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00
Intel segment tagging	Home Office, Small Business
HP segment	Business
HP Security tools	HP Secure Erase, HP Client Security, HP Security Manager
HP Management tools	HP Driver Packs, HP SoftPaq Download Manager, HP System Software Manager, HP BIOS Config Utility, HP Client Catalog, HP MIK
HP Software provided	HP BIOSphere, HP SureStart, HP Password Manager, HP Spare Key, HP Device Access Manager, HP DriveLock, HP Hotkey Support, HP Noise Cancellation; HP Image Assistant
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	218.5 mm
Width	316.9 mm
Height	14.9 mm
Weight	1280 g
