HP EliteDisplay E221 Specification

Humidity - Non-operating 5% to 95%, 38.7° C max wet-bulb
Altitude - Operating 0 to 5,000 m (16,404 ft)
Altitude - Non-operating 0 to 12,192 m (0 to 40,000 ft)
White LED Backlights Yes
CCFL Panel No
Arsenic-Free Display
Glass
4
Yes
Low Halogen
5
Yes
Mercury- Free Display
Backlighting
Yes
Environmental Data Eco-Label
Certifications &
Declarations
This product has received or is in the process of being certified to the following
approvals and may be labeled with one or more of these marks:
IT ECO declaration
US ENERGY STAR®
TCO 06
EPEAT® Gold where HP registers commercial display products. See
http://www.epeat.net for registration status in your country US Federal
Energy Management Program (FEMP)
Energy Consumption
(in accordance with US
Energy Star test
method) 115VAC, 60Hz 230VAC, 50Hz 100VAC, 60Hz
Normal Operation 18.57 W 18.66 W 18.69 W
Sleep 0.25 W 0.28 W 0.25 W
Off 0.19 W 0.23 W 0.18 W
Heat Dissipation * 115VAC, 60 Hz 230VAC, 50 Hz 100VAC, 60 Hz
Normal Operation 64 BTU/hr 64 BTU/hr 64 BTU/hr
Sleep 1 BTU/hr 1 BTU/hr 1 BTU/hr
Off 1 BTU/hr 1 BTU/hr 1 BTU/hr
*NOTE: Heat dissipation is calculated based on the measured watts, assuming the service level is attained for
one hour.
Additional Information This product is in compliance with the Restrictions of Hazardous Substances
(RoHS) directive - 2002/95/EC.
This HP product is designed to comply with the Waste Electrical and
Electronic Equipment (WEEE) Directive - 2002/96/EC.
This product is in compliance with California Proposition 65 (State of
California; Safe Drinking Water and Toxic Enforcement Act of 1986).
This product is in compliance with the IEEE 1680 (EPEAT) standard at the Gold
level, see www.epeat.net
Plastics parts weighing over 25 grams used in the product are marked per ISO
11469 and ISO1043.
This product contains 17.4 % post-consumer recycled plastic (by wt.)
This product is 98.5 % recycle-able when properly disposed of at end of life.
QuickSpecs
HP EliteDisplay E221 21.5-inch LED Backlit Monitor
Technical Specifications
DA - 14551 North America — Version 7 — July 18, 2013 Page 5

HP EliteDisplay E221 Specifications

General

3D	No
Product type	PC monitor
Display diagonal	21.5 \
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	5000000:1
Contrast ratio (typical)	1000:1
Display number of colors	-
Viewing angle, horizontal	170 °
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	720 x 400, 1400 x 900, 1600 x 900, 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 640 x 480 (VGA), 800 x 600 (SVGA)
HDCP	Yes
USB hub version	2.0
HDMI ports quantity	0
USB Type-A downstream ports quantity	3
Pivot angle	0 - 90 °
Tilt angle range	-5 - 30 °
Panel mounting interface	- mm
Power consumption (max)	36 W
Power consumption (standby)	0.5 W
Power consumption (typical)	30 W
Product color	Black
Country of origin	China
Market positioning	Business
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Package weight	7100 g
Sustainability certificates	EPEAT Gold, ENERGY STAR

Weight and Dimensions

Depth (without stand)	237 mm
Width (without stand)	509 mm
Height (without stand)	460 mm
Weight (without stand)	5640 g
