HP EliteDisplay E221c User Manual

This product is 98.2 % recycle-able when properly disposed of at end of
life.
Packaging Materials External: PAPER/Corrugated 808 g
Internal: PLASTIC/EPS (Expanded
Polystyrene)
328 g
PLASTIC/EPE-Expanded
Polyethylene
48 g
RoHS Compliance Hewlett-Packard is committed to compliance with all applicable environmental
laws and regulations, including the European Union Restriction of Hazardous
Substances (RoHS) Directive. HP's goal is to exceed compliance obligations by
meeting the requirements of the RoHS Directive on a worldwide basis. By July 1,
2006, RoHS substances will be virtually eliminated (virtually = to levels below
legal limits) for all HP electronic products subject to the RoHS Directive, except
where it is widely recognized that there is no technically feasible alternative (as
indicated by an exemption under the EU RoHS Directive).
Material Usage This product does not contain any of the following substances in excess of
regulatory limits (refer to the HP General Specification for the Environment at
http://www.hp.com/hpinfo/globalcitizenship/environment/
supplychain/gen_specifications.html ):
Asbestos
Certain Azo Colorants
Certain Brominated Flame Retardants – may not be used as flame
retardants in plastics
Cadmium
Chlorinated Hydrocarbons
Chlorinated Paraffins
Formaldehyde
Halogenated Diphenyl Methanes
Lead carbonates and sulfates
Lead and Lead compounds
Mercuric Oxide Batteries
Nickel - finishes must not be used on the external surface designed to be
frequently handled or carried by the user.
Ozone Depleting Substances
Polybrominated Biphenyls (PBBs)
Polybrominated Biphenyl Ethers (PBBEs)
Polybrominated Biphenyl Oxides (PBBOs)
Polychlorinated Biphenyl (PCB)
Polychlorinated Terphenyls (PCT)
Polyvinyl Chloride (PVC) - except for wires and cables, and certain retail
packaging has been voluntarily removed from most applications.
Radioactive Substances
Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)
Packaging HP follows these guidelines to decrease the environmental impact of product
packaging:
Eliminate the use of heavy metals such as lead, chromium, mercury and
cadmium in packaging materials.
Eliminate the use of ozone-depleting substances (ODS) in packaging
QuickSpecs
HP EliteDisplay E221c 21.5-inch Webcam LED Backlit
Monitor
Technical Specifications
DA - 14664 North America — Version 2 — September 4, 2013 Page 6

HP EliteDisplay E221c Specifications

General

3D	No
Color gamut	72 %
Pixel pitch	0.248 x 0.248 mm
Aspect ratio	16:9
Display surface	Matt
Display diagonal	21.5 \
Display technology	LED
Vertical scan range	50 - 76 Hz
Horizontal scan range	24 - 94 kHz
Supported video modes	1080p
Viewable size, vertical	268.1 mm
Contrast ratio (dynamic)	5000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	476.6 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	-
On/off switch	Yes
USB hub version	2.0
HDMI ports quantity	0
Headphone connectivity	3.5 mm
USB Type-A downstream ports quantity	3
RMS rated power	1 W
Number of speakers	2
Certification	TCO Edge\\r CE\\r CB\\r KC\\r KCC\\r NOM\\r PSB\\r ICE\\r TUV-S\\r CCC\\r CEL Grade 1\\r CECP\\r SEPA\\r VCCI\\r FCC\\r Taiwan BSMI
Product color	Black
Country of origin	China
Market positioning	Business
Pivot angle	0 - 90 °
LED indicators	Power
Tilt angle range	-5 - 30 °
Panel mounting interface	100 x 100 mm
AC input voltage	90 - 256 V
AC input frequency	47/63 Hz
Power consumption (max)	42 W
Power consumption (standby)	0.4 W
Power consumption (typical)	27 W
Sustainability certificates	EPEAT Silver, ENERGY STAR
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	20 - 90 %
Operating relative humidity (H-H)	20 - 70 %
Package depth	184 mm
Package width	575 mm
Package height	500 mm
Package weight	7100 g
Cables included	AC, DisplayPort, USB, VGA

Weight and Dimensions

Depth (with stand)	237 mm
Height (with stand)	460 mm
Depth (without stand)	51 mm
Width (without stand)	509 mm
Height (without stand)	309 mm
Weight (without stand)	5400 g
