HP EliteDisplay E221c User Manual

Humidity - Operating 20% to 80% non-condensing
Humidity - Non-operating 5% to 95%, 38.7° C max wet-bulb
Altitude - Operating 0 to 5,000 m (16,404 ft)
Altitude - Non-operating 0 to 12,192 m (0 to 40,000 ft)
White LED Backlights Yes
CCFL Panel No
Arsenic-Free Display
Glass
Yes
Low Halogen
4
Yes
Mercury- Free Display
Backlighting
Yes
Environmental Data Eco-Label Certifications
& declarations
This product has received or is in the process of being certified to the following
approvals and may be labeled with one or more of these marks:
IT ECO declaratio
US ENERGY STAR®
TCO 6.0 and TCO Edge Certification
EPEAT® Gold where HP registers commercial display products. See
http://www.epeat.net for registration status in your country US Federal
Energy Management Program (FEMP)
Energy Consumption
(in accordance with US
ENERGY STAR® test
method) 115VAC, 60Hz 230VAC, 50Hz 100VAC, 60Hz
Normal Operation 20.6 W 20.4 W 20.8 W
Sleep 0.4 W 0.4 W 0.4 W
Off 0.2 W 0.2 W 0.2 W
Heat Dissipation * 115VAC, 60Hz 230VAC, 50Hz 100VAC, 60Hz
Normal Operation 70 BTU/hr 70 BTU/hr 71 BTU/hr
Sleep 1 BTU/hr 1 BTU/hr 1 BTU/hr
Off 1 BTU/hr 1 BTU/hr 1 BTU/hr
* Heat dissipation is calculated based on the measured watts, assuming the
service level is attained for one hour.
Additional Information This product is in compliance with the Restrictions of Hazardous
Substances (RoHS) directive - 2002/95/EC.
This HP product is designed to comply with the Waste Electrical and
Electronic Equipment (WEEE) Directive - 2002/96/EC.
This product is in compliance with California Proposition 65 (State of
California; Safe Drinking Water and Toxic Enforcement Act of 1986).
This product is in compliance with the IEEE 1680 (EPEAT) standard at the
Gold level, see www.epeat.net
Plastics parts weighing over 25 grams used in the product are marked per
ISO 11469 and ISO1043.
This product contains 12.9 % post-consumer recycled plastic (by wt.)
QuickSpecs
HP EliteDisplay E221c 21.5-inch Webcam LED Backlit
Monitor
Technical Specifications
DA - 14664 North America — Version 2 — September 4, 2013 Page 5

HP EliteDisplay E221c Specifications

General

3D	No
Color gamut	72 %
Pixel pitch	0.248 x 0.248 mm
Aspect ratio	16:9
Display surface	Matt
Display diagonal	21.5 \
Display technology	LED
Vertical scan range	50 - 76 Hz
Horizontal scan range	24 - 94 kHz
Supported video modes	1080p
Viewable size, vertical	268.1 mm
Contrast ratio (dynamic)	5000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	476.6 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	-
On/off switch	Yes
USB hub version	2.0
HDMI ports quantity	0
Headphone connectivity	3.5 mm
USB Type-A downstream ports quantity	3
RMS rated power	1 W
Number of speakers	2
Certification	TCO Edge\\r CE\\r CB\\r KC\\r KCC\\r NOM\\r PSB\\r ICE\\r TUV-S\\r CCC\\r CEL Grade 1\\r CECP\\r SEPA\\r VCCI\\r FCC\\r Taiwan BSMI
Product color	Black
Country of origin	China
Market positioning	Business
Pivot angle	0 - 90 °
LED indicators	Power
Tilt angle range	-5 - 30 °
Panel mounting interface	100 x 100 mm
AC input voltage	90 - 256 V
AC input frequency	47/63 Hz
Power consumption (max)	42 W
Power consumption (standby)	0.4 W
Power consumption (typical)	27 W
Sustainability certificates	EPEAT Silver, ENERGY STAR
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	20 - 90 %
Operating relative humidity (H-H)	20 - 70 %
Package depth	184 mm
Package width	575 mm
Package height	500 mm
Package weight	7100 g
Cables included	AC, DisplayPort, USB, VGA

Weight and Dimensions

Depth (with stand)	237 mm
Height (with stand)	460 mm
Depth (without stand)	51 mm
Width (without stand)	509 mm
Height (without stand)	309 mm
Weight (without stand)	5400 g
