3
Remove the
pins
Remove the
pins
Remove the
Middle_Frame
and the
Mainframe
Remove the
screws to
remove the
Middle frame
and the
Mainframe
Remove the
screws and the
Pin
Remove the
screws and the
pin
The Key Board
