HP EliteDisplay E273m User Manual

50
12. Mechanical Instructions
Step
Figure
Description
Preparation
Lay the monitor
on a flat, soft
and clean
surface.
Remove the
Stand-base
Ass’y
Push the button
the remove the
stand-base
ass’y
Remove the
Rear cover
Remove the
screws to
remove the
Rear cover.

HP EliteDisplay E273m Specifications

General

3D	No
Color gamut	72 %
Pixel pitch	0.311 x 0.311 mm
Screen shape	Flat
Pixel density	81.59 ppi
Display diagonal	27 \
Display technology	LED
Native aspect ratio	16:9
Vertical scan range	50 - 60 Hz
Maximum refresh rate	60 Hz
Horizontal scan range	30 - 80 kHz
Viewable size, vertical	336.3 mm
Contrast ratio (dynamic)	5000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	597.8 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+)
Depth	47.5 mm
Width	610 mm
Height	389 mm
Weight	7900 g
On/off switch	Yes
Pivot angle	0 - 90 °
Tilt angle range	-5 - 22 °
Number of OSD languages	10
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, DUT, ENG, ESP, FRE, ITA, JPN, POR
AC input voltage	100 - 240 V
Energy efficiency scale	A to G
Power consumption (max)	68 W
Annual energy consumption	37 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	32 W
USB hub version	3.2 Gen 1 (3.1 Gen 1)
USB upstream port type	USB Type-C
Number of upstream ports	1
USB Type-A downstream ports quantity	2
Operating altitude	0 - 5000 m
Non-operating altitude	5000 - 12192 m
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	EPEAT Gold, ENERGY STAR
RMS rated power	4 W
Product color	Black, Silver
Country of origin	China
Market positioning	Business
Cables included	AC, DisplayPort, USB Type-C to USB Type-A, VGA
Package weight	11230 g
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	214 mm
Height (with stand)	384 mm
Weight (without stand)	5050 g
