HP G60 Maintenance And Service Guide

Screw listing 7–15
Phillips PM2.0x10.0 captive screw
Where used: 4 screws that secure the fan/heat sink to the base enclosure (screws are secured by C-clips) on
computer models equipped with graphics subsystems with UMA memory
Color Quantity Length Thread Head diameter
Silver 4 10.0 mm 2.0 mm 5.0 mm

HP G60 Specifications

General

Wireless	802.11b/g WLAN
Audio	Altec Lansing speakers
Display	15.6-inch HD BrightView (1366x768)
Optical Drive	DVD±RW DL LightScribe
Battery	6-cell Lithium-Ion
Ports	3 x USB 2.0, 1 x HDMI, 1 x VGA, 1 x Headphone, 1 x Microphone
Webcam	Integrated webcam
Processor	Intel or AMD (various models available)
RAM	4GB DDR2
Graphics	Intel GMA 4500MHD or NVIDIA GeForce 8200M G
Weight	Starting at 2.75 kg
