Illustrated parts catalog 3–13
496878-B31 Keyboard for use in the Netherlands
496878-DJ1 Keyboard for use in Greece
496880-001 Base enclosure (includes power connector cable, power connector cable bracket, and 7 rubber feet)
496881-001 Top cover (includes fingerprint reader board, fingerprint reader board cable, TouchPad, and
TouchPad cable)
496882-001 Switch cover
496883-001 Keyboard cover (includes LED board and cable)
496887-001 Speaker assembly
496888-001 Plastics Kit
✎
See “Plastics Kit” on page 3-9 for more Plastics Kit spare part information.
496889-001 Rubber Feet Kit (includes 7 rubber feet)
496890-001 Screw Kit
496891-001 Cable Kit
496892-001 Audio/infrared board (includes cable)
496893-001 Subwoofer (includes 3 mounting grommets)
496894-001 Fan/heat sink assembly for use with all processors except the Intel Core2 Duo QX9300, 2.53-GHz
processor (includes replacement thermal material)
497692-001 1024-MB memory module (667-MHz, PC2-6400, 1-DIMM)
497693-001 2048-MB memory module (667-MHz, PC2-6400, 1-DIMM)
497705-001 8-cell, 73-Wh, 2.55-Ah Li-ion battery for use in all countries and regions except Germany
497705-002 8-cell, 73-Wh, 2.55-Ah Li-ion battery for use only in Germany
497706-001 USB board (includes cable)
498166-001 18.4-inch, AntiGlare, dual-lamp, display assembly (includes 2 WLAN antenna transceivers and
cables, webcam, microphones, and logo)
✎
See “Display assembly components” on page 3-7 for information on display assembly spare
part numbers.
498324-001 Display inverter
498325-001 Power button board (includes cable)
499242-001 Webcam/microphone module
500506-001 TouchPad on/off button board (incudes cable)
500600-001 Intel Core2 Duo T8400 2.26-GHz processor with 3-MB L2 cache and 1066-MHz FSB (includes
replacement thermal material)
500601-001 Intel Core2 Duo T8600 2.40-GHz processor with 3-MB L2 cache and 1066-MHz FSB (includes
replacement thermal material)
500603-001 Intel Core2 Duo T9500 2.53-GHz processor with 6-MB L2 cache and 1066-MHz FSB (includes
replacement thermal material)
500604-001 Intel Core2 Duo T9600 2.80-GHz processor with 6-MB L2 cache and 1066-MHz FSB (includes
replacement thermal material)
500606-001 Intel Core2 Duo QX9300 2.53-GHz processor with 12-MB L2 cache and 1066-MHz FSB (includes
replacement thermal material)
500607-001 80-GB, 5400-rpm hard drive (includes left and right hard drive brackets, Mylar sleeve, connector, and
isolators)
(Continued)
Spare part number Description
