HP JD320B Installation Guide

42
Item
A3100-24-PoE v2 EI
A3100-16-PoE v2 EI
A3100-8-PoE v2 EI
Melting current of
power supply fuse
AC: 10A
DC: 25A
10 A
3.15 A
Max output
power/PoE port
15.4 W
15.4 W
15.4 W
PoE ports
24
8
4
Total PoE output
power
370 W
135 W
70 W
Power consumption
(minimum hardware
and software
configuration)
20 W
16 W
20 W
Power consumption
(full hardware
configuration, all PoE
ports are supplying
power)
AC: 465 W
DC: 400 W
160 W
95 W
Max thermal output
AC: 1586.6265 BTU/h
DC: 1364.8400 BTU/h
545.936 BTU/h
324.1495 BTU/h
Cooling system
Built-in fans
Built-in fans
Built-in fans
Operating
temperature
0°C to 45°C (32°F to 113°F)
Relative humidity
(noncondensing)
10% to 90%
Fire resistance
compliance
UL60950-1, EN60950-1, IEC60950-1, GB4943
Chassis leakage
current compliance
UL60950-1, EN60950-1, IEC60950-1, GB4943
Table 13 PoE switches fan specifications
Item
A3100-24-PoE v2 EI
A3100-16-PoE v2 EI
A3100-8-PoE v2 EI
Fans
4
2
2
Airflow
direction
Left side to right side
Left side to right side
Left side to right side
Fan speed
8200 RPM
8200 RPM
6300 RPM
Max airflow
9.4 × 4 CFM
9.4 × 2 CFM
7.17 × 2 CFM
Max power
consumption
1.2 × 4 W
1.2 × 2 W
0.72 × 2 W
Min power
consumption
0.84 × 4 W
0.84 × 2 W
0.5 × 2 W
