3-2 Installing the HP Jetdirect 170X Print Server
LEDs
On the top of the 170X are Status and LAN Activity LEDs
If the
Status
LED is...
And the
Activity
LED is... Then the print server is...
Off Off Not receiving power.
On Off On; no LAN activity detected.
On Blinking On; LAN activity detected.
Off On (Solid) Encountering a fault during self-test or operation.
Blinking Off Encountering one of the following conditions:
●
running a self-test.
●
not configured.
●
not able to attach to the network.
On On On; heavy LAN activity detected.
0Book-asF01.book Page 2 Tuesday, August 14, 2001 2:06 PM
