Page #42 background image
15" LCD Color Monitor HP L1506
42
Q601 57G 417 13 T 2N3906S-RTK/PS SOT-23
Q603 57G 417 13 T 2N3906S-RTK/PS SOT-23
Q203 57G 763 1 AO3401L SOT23 BY AOS(A1
RP601 61G 125103 86857 RST CHIPR 10KOHM +-5% 1
RP602 61G 125103 86857 RST CHIPR 10KOHM +-5% 1
RP603 61G 125103 86857 RST CHIPR 10KOHM +-5% 1
RP604 61G 125103 86857 RST CHIPR 10KOHM +-5% 1
FB301 61G0603000 6857 RST CHIPR 0 OHM +-5% 1/
FB302 61G0603000 6857 RST CHIPR 0 OHM +-5% 1/
FB303 61G0603000 6857 RST CHIPR 0 OHM +-5% 1/
R210 61G0603000 6857 RST CHIPR 0 OHM +-5% 1/
R641 61G0603000 6857 RST CHIPR 0 OHM +-5% 1/
R309 61G0603101 6857 RST CHIPR 100 OHM +-5%
R312 61G0603101 6857 RST CHIPR 100 OHM +-5%
R608 61G0603101 6857 RST CHIPR 100 OHM +-5%
R609 61G0603101 6857 RST CHIPR 100 OHM +-5%
R610 61G0603101 6857 RST CHIPR 100 OHM +-5%
R611 61G0603101 6857 RST CHIPR 100 OHM +-5%
R636 61G0603101 6857 RST CHIPR 100 OHM +-5%
C511 61G0603102 6857 RST CHIPR 1KOHM +-5% 1/
R203 61G0603102 6857 RST CHIPR 1KOHM +-5% 1/
R310 61G0603102 6857 RST CHIPR 1KOHM +-5% 1/
R311 61G0603102 6857 RST CHIPR 1KOHM +-5% 1/
R620 61G0603102 6857 RST CHIPR 1KOHM +-5% 1/
R621 61G0603102 6857 RST CHIPR 1KOHM +-5% 1/
R623 61G0603102 6857 RST CHIPR 1KOHM +-5% 1/
R624 61G0603102 6857 RST CHIPR 1KOHM +-5% 1/
R202 61G0603103 6857 RST CHIPR 10KOHM +-5% 1
R208 61G0603103 6857 RST CHIPR 10KOHM +-5% 1
R211 61G0603103 6857 RST CHIPR 10KOHM +-5% 1
R308 61G0603103 6857 RST CHIPR 10KOHM +-5% 1
R329 61G0603103 6857 RST CHIPR 10KOHM +-5% 1
R601 61G0603103 6857 RST CHIPR 10KOHM +-5% 1
R602 61G0603103 6857 RST CHIPR 10KOHM +-5% 1
R603 61G0603103 6857 RST CHIPR 10KOHM +-5% 1
R604 61G0603103 6857 RST CHIPR 10KOHM +-5% 1
R605 61G0603103 6857 RST CHIPR 10KOHM +-5% 1
R606 61G0603103 6857 RST CHIPR 10KOHM +-5% 1
R607 61G0603103 6857 RST CHIPR 10KOHM +-5% 1
R613 61G0603103 6857 RST CHIPR 10KOHM +-5% 1
