HP L1506 User Manual

15" LCD Color Monitor HP L1506
45
C304 65G0603473 326857 CHIP 0.047UF 50V X7R
C305 65G0603473 326857 CHIP 0.047UF 50V X7R
C306 65G0603473 326857 CHIP 0.047UF 50V X7R
C308 65G0603473 326857 CHIP 0.047UF 50V X7R
C309 65G0603473 326857 CHIP 0.047UF 50V X7R
C310 65G0603473 326857 CHIP 0.047UF 50V X7R
C311 65G0603680 316857 CHIP 68PF 50V NPO
FB202 71G 56Z601 6457 CHIP BEAD 600 OHM 0805
FB401 71G 56Z601 6457 CHIP BEAD 600 OHM 0805
FB402 71G 56Z601 6457 CHIP BEAD 600 OHM 0805
FB403 71G 56Z601 6457 CHIP BEAD 600 OHM 0805
FB404 71G 56Z601 6457 CHIP BEAD 600 OHM 0805
FB405 71G 56Z601 6457 CHIP BEAD 600 OHM 0805
FB406 71G 56Z601 6457 CHIP BEAD 600 OHM 0805
R204 71G 59B121 6888 TB160808B
D304 93G 64 42 P BAV70 SOT-23
D601 93G 6432S 1N4148W
D301 93G 6433P BAV99
D302 93G 6433P BAV99
D303 93G 6433P BAV99
D317 93G 39S 34 T UDZS5.6B
D318 93G 39S 34 T UDZS5.6B
D319 93G 39S 34 T UDZS5.6B
D320 93G 39S 34 T UDZS5.6B
D321 93G 39S 34 T UDZS5.6B
D322 93G 39S 34 T UDZS5.6B
D323 93G 39S 34 T UDZS5.6B
D201 93G1004 3 SS14
D202 93G1020 1 S GS1D
715G1533 2 MS6905 MAIN BOARD PCB
SW1 77G 600 1GCJ TACT SWITCH TSPB-2
DP1 81G 12 1F GP6356 LED
CN201 95G8014 45156078 HARNESS
715G1532 2 P6F2I KEPC PCB
CN102 33G3802 4H 6176 WAFER 4P RIGHT ANGLE
CN101 33G8027 8 H6176 WAFER 8P 2.0mm DIP DUAL
SW2 77G 600 1GCJ TACT SWITCH TSPB-2
SW3 77G 600 1GCJ TACT SWITCH TSPB-2
SW4 77G 600 1GCJ TACT SWITCH TSPB-2
715G1532 3 K6F2I KEPC PCB

HP L1506 Specifications

General

3D	No
Pixel pitch	0.297 x 0.297 mm
Aspect ratio	4:3
Response time	8 ms
Display diagonal	15 \
Display resolution	1024 x 768 pixels
Vertical scan range	56 - 76 Hz
Horizontal scan range	30 - 61 kHz
Viewing angle, vertical	100 °
Contrast ratio (dynamic)	-
Contrast ratio (typical)	450:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	130 °
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	720 x 400, 832 x 624, 1024 x 768 (XGA), 640 x 480 (VGA), 800 x 600 (SVGA)
On/off switch	Yes
DVI-D ports quantity	0
Tilt angle range	-5 - 30 °
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	23 W
Power consumption (standby)	2 W
Power consumption (typical)	21 W
Certification	CISPR, VCCI, CSA, TUV, GS, CCC, MIC, FCC, UL, GOST, SASO
Product color	Silver
Country of origin	China
Market positioning	Business
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	5 - 90 %
Package weight	4500 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	203 mm
Height (with stand)	355 mm
Weight (with stand)	3200 g
Depth (without stand)	60 mm
Width (without stand)	340 mm
Height (without stand)	290 mm
Weight (without stand)	- g
