HP L1506 User Manual

15" LCD Color Monitor HP L1506
57
E715 715G1533 2 MS6905 MAIN BOARD PCB
SW1 77G 600 1GCJ TACT SWITCH TSPB-2
DP1 81G 12 1F GP LED 3Φ
CN201 95G8014 45156078 HARNESS
715G1532 2 P6F2I KEPC BOARD PCB
CN102 33G3802 4H 6176 WAFER 4P RIGHT ANGLE
CN101 33G8027 8 H6176 WAFER 8P 2.0mm DIP DUAL
SW2 77G 600 1GCJ TACT SWITCH TSPB-2
SW3 77G 600 1GCJ TACT SWITCH TSPB-2
SW4 77G 600 1GCJ TACT SWITCH TSPB-2
E715 715G1532 3 K6F2I KEPC BOARD PCB
L902 S73L17440VG TRANSFORMER
L901 S73L17455VG LINE FILTER BY TPV
CN801 33G8020 2E U WAFER
CN802 33G8020 2E U WAFER
CN901 33G8029 5A 6065 WAFER
40G 45762412B CBPC LABEL
IC902 56G 139 3A PC123Y22FZOF
NR901 61G 58080 WT6872 RST NTCR 8 OHM
R904 61G152M39858F6W56 RST MOFR 0.39 OHM +-5%
C903 63G107K474 US 0.47UF +-10%
C818 65G 3J1506ET 15PF 5% CC45SL 3KV TDK
C843 65G 3J1506ET 15PF 5% CC45SL 3KV TDK
C826 65G 3J5096ET 5PF 5% 3KV TDK
C827 65G 3J5096ET 5PF 5% 3KV TDK
C901 65G305M2222BP6W29 CAP Y2 2200PF M 250V
C902 65G305M2222BP6W29 CAP Y2 2200PF M 250V
C921 65G306M4722BP6W29 CAP Y1 4700PF M 250V
C904 67G215S4713KV ELCAP 470UF +-20% 16V 1
C906 67G215S4713KV ELCAP 470UF +-20% 16V 1
C908 67G215S4713KV ELCAP 470UF +-20% 16V 1
C909 67G215S4713KV ELCAP 470UF +-20% 16V 1
C911 67G215S4713KV ELCAP 470UF +-20% 16V 1
C845 67G215V102 3R ELCAP 1000UF +-20% 16V
C905 67G215Z10115K ELCAP 100UF +-20% 450V
L903 73G 253 91 H CHOKE COIL
L904 73G 253 91 H CHOKE COIL
T901 80GL15T 19 N TRANSFORMER BY YUVA
PT801 80GL15T 20 H TRANSFORMER BY YUVA
CN902 95G8014 125176W72 CONNECTOR

HP L1506 Specifications

General

3D	No
Pixel pitch	0.297 x 0.297 mm
Aspect ratio	4:3
Response time	8 ms
Display diagonal	15 \
Display resolution	1024 x 768 pixels
Vertical scan range	56 - 76 Hz
Horizontal scan range	30 - 61 kHz
Viewing angle, vertical	100 °
Contrast ratio (dynamic)	-
Contrast ratio (typical)	450:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	130 °
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	720 x 400, 832 x 624, 1024 x 768 (XGA), 640 x 480 (VGA), 800 x 600 (SVGA)
On/off switch	Yes
DVI-D ports quantity	0
Tilt angle range	-5 - 30 °
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	23 W
Power consumption (standby)	2 W
Power consumption (typical)	21 W
Certification	CISPR, VCCI, CSA, TUV, GS, CCC, MIC, FCC, UL, GOST, SASO
Product color	Silver
Country of origin	China
Market positioning	Business
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	5 - 90 %
Package weight	4500 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	203 mm
Height (with stand)	355 mm
Weight (with stand)	3200 g
Depth (without stand)	60 mm
Width (without stand)	340 mm
Height (without stand)	290 mm
Weight (without stand)	- g
