15" LCD Color Monitor HP L1506
64
C419 67G405V100 3P ELCAP 10UF +-20% 16V 10
C422 67G405V100 3P ELCAP 10UF +-20% 16V 10
C424 67G405V100 3P ELCAP 10UF +-20% 16V 10
C427 67G405V100 3P ELCAP 10UF +-20% 16V 10
C603 67G405V100 3P ELCAP 10UF +-20% 16V 10
C509 67G405V220 3P ELCAP 22UF +-20% 16V 10
C211 67G405V470 3P ELCAP 47UF +-20% 16V 10
C213 67G405V470 3P ELCAP 47UF +-20% 16V 10
C215 67G405V470 3P ELCAP 47UF +-20% 16V 10
CN301 88G 35315F HJ SOC SUBD H 15P F
Y601 93G 22 45 J 24MHZ/30PF/49US
X401 93G 22 53 J 14.31818MHZ/32PF/49US
U401 56G 562 88 TSU13AK BY MST
U202 56G 563 21 AP1084K33LA
U201 56G 563 31 AZ1117D-1.8-E1
U601 56G1125543HP6 MTV512GM
U301 56G1133 34 M24C02-WMN6TP
U602 56G1133 56 M24C16-WMN6TP
Q201 57G 417 12 T 2N3904S-RTK/PS SOT-23
Q202 57G 417 12 T 2N3904S-RTK/PS SOT-23
Q204 57G 417 12 T 2N3904S-RTK/PS SOT-23
Q301 57G 417 12 T 2N3904S-RTK/PS SOT-23
Q601 57G 417 13 T 2N3906S-RTK/PS SOT-23
Q603 57G 417 13 T 2N3906S-RTK/PS SOT-23
Q203 57G 763 1 AO3401L SOT23 BY AOS(A1
RP601 61G 125103 86857 RST CHIPR 10KOHM +-5% 1
RP602 61G 125103 86857 RST CHIPR 10KOHM +-5% 1
RP603 61G 125103 86857 RST CHIPR 10KOHM +-5% 1
RP604 61G 125103 86857 RST CHIPR 10KOHM +-5% 1
FB301 61G0603000 6857 RST CHIPR 0 OHM +-5% 1/
FB302 61G0603000 6857 RST CHIPR 0 OHM +-5% 1/
FB303 61G0603000 6857 RST CHIPR 0 OHM +-5% 1/
R210 61G0603000 6857 RST CHIPR 0 OHM +-5% 1/
R641 61G0603000 6857 RST CHIPR 0 OHM +-5% 1/
R309 61G0603101 6857 RST CHIPR 100 OHM +-5%
R312 61G0603101 6857 RST CHIPR 100 OHM +-5%
R608 61G0603101 6857 RST CHIPR 100 OHM +-5%
R609 61G0603101 6857 RST CHIPR 100 OHM +-5%
R610 61G0603101 6857 RST CHIPR 100 OHM +-5%
R611 61G0603101 6857 RST CHIPR 100 OHM +-5%

HP L1506 Specifications

General

3D	No
Pixel pitch	0.297 x 0.297 mm
Aspect ratio	4:3
Response time	8 ms
Display diagonal	15 \
Display resolution	1024 x 768 pixels
Vertical scan range	56 - 76 Hz
Horizontal scan range	30 - 61 kHz
Viewing angle, vertical	100 °
Contrast ratio (dynamic)	-
Contrast ratio (typical)	450:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	130 °
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	720 x 400, 832 x 624, 1024 x 768 (XGA), 640 x 480 (VGA), 800 x 600 (SVGA)
On/off switch	Yes
DVI-D ports quantity	0
Tilt angle range	-5 - 30 °
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	23 W
Power consumption (standby)	2 W
Power consumption (typical)	21 W
Certification	CISPR, VCCI, CSA, TUV, GS, CCC, MIC, FCC, UL, GOST, SASO
Product color	Silver
Country of origin	China
Market positioning	Business
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	5 - 90 %
Package weight	4500 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	203 mm
Height (with stand)	355 mm
Weight (with stand)	3200 g
Depth (without stand)	60 mm
Width (without stand)	340 mm
Height (without stand)	290 mm
Weight (without stand)	- g
