15" LCD Color Monitor HP L1506
71
R914 61G1206339 6857 RST CHIPR 3.3 OHM +-5%
R909 61G1206434 6857 RST CHIPR 430KOHM +-5%
R910 61G1206434 6857 RST CHIPR 430KOHM +-5%
R931 61G1206434 6857 RST CHIPR 430KOHM +-5%
R838 61G1206471 6857 RST CHIPR 470 OHM +-5%
R907 61G1206514 6857 RST CHIPR 510KOHM +-5%
R908 61G1206514 6857 RST CHIPR 510KOHM +-5%
R932 61G1206514 6857 RST CHIPR 510KOHM +-5%
R901 61G1206684 6857 RST CHIPR 680KOHM +-5%
R902 61G1206684 6857 RST CHIPR 680KOHM +-5%
R903 61G1206684 6857 RST CHIPR 680KOHM +-5%
C803 65G0805104 326029 CAP 0805 0.1UF +-10% 50
C820 65G0805104 326029 CAP 0805 0.1UF +-10% 50
C823 65G0805104 326029 CAP 0805 0.1UF +-10% 50
C828 65G0805104 326029 CAP 0805 0.1UF +-10% 50
C833 65G0805104 326029 CAP 0805 0.1UF +-10% 50
C834 65G0805104 326029 CAP 0805 0.1UF +-10% 50
C837 65G0805104 326029 CAP 0805 0.1UF +-10% 50
C838 65G0805104 326029 CAP 0805 0.1UF +-10% 50
C848 65G0805104 326029 CAP 0805 0.1UF +-10% 50
C907 65G0805104 326029 CAP 0805 0.1UF +-10% 50
C910 65G0805104 326029 CAP 0805 0.1UF +-10% 50
C914 65G0805104 326029 CAP 0805 0.1UF +-10% 50
C918 65G0805104 326029 CAP 0805 0.1UF +-10% 50
C934 65G0805104 326029 CAP 0805 0.1UF +-10% 50
C819 65G0805105 226805 CHIP 1UF 25V X7R 0805
C835 65G0805105 226805 CHIP 1UF 25V X7R 0805
C839 65G0805105 226805 CHIP 1UF 25V X7R 0805
C919 65G0805221 216029 220PF 25V 5%
C917 65G0805223 326029 CAP 0805 0.022UF 50V X7
C912 65G0805334 226857 0.33UF+-10% 25V X7R 080
C802 65G0805392 316826 CHIP 3900PF 50V X7R 080
C811 65G0805471 216857 CHIP 470PF 25V NPO
C801 65G0805471 316826 CHIP 470PF 50V NPO
C810 65G0805472 316826 CHIP 4700PF 50V X7R 080
C832 65G0805472 316826 CHIP 4700PF 50V X7R 080
C821 65G0805473 326029 CAP 0805 0.047UFK 50V X
C829 65G0805473 326029 CAP 0805 0.047UFK 50V X
C836 65G0805474 226826 CHIP 0.47UF 25V X7R 080
C931 65G1206102 726805 CHIP 1000PF 500V X7R

HP L1506 Specifications

General

3D	No
Pixel pitch	0.297 x 0.297 mm
Aspect ratio	4:3
Response time	8 ms
Display diagonal	15 \
Display resolution	1024 x 768 pixels
Vertical scan range	56 - 76 Hz
Horizontal scan range	30 - 61 kHz
Viewing angle, vertical	100 °
Contrast ratio (dynamic)	-
Contrast ratio (typical)	450:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	130 °
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	720 x 400, 832 x 624, 1024 x 768 (XGA), 640 x 480 (VGA), 800 x 600 (SVGA)
On/off switch	Yes
DVI-D ports quantity	0
Tilt angle range	-5 - 30 °
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	23 W
Power consumption (standby)	2 W
Power consumption (typical)	21 W
Certification	CISPR, VCCI, CSA, TUV, GS, CCC, MIC, FCC, UL, GOST, SASO
Product color	Silver
Country of origin	China
Market positioning	Business
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	5 - 90 %
Package weight	4500 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	203 mm
Height (with stand)	355 mm
Weight (with stand)	3200 g
Depth (without stand)	60 mm
Width (without stand)	340 mm
Height (without stand)	290 mm
Weight (without stand)	- g
