HP L1506 User Manual

15" LCD Color Monitor HP L1506
77
FRAME
0M1G1730 6120 SCREW,42-D020523
POWER / MAIN
FRAME
0M1G1740 6120 SCREW
0M1G2940 10225 CR3 SCREW
0M1G3030 5 47 CR3 SCREW
0Q1G 330 6120 SCREW 42A9930001
OSD PCB
BOARD / REAR
0Q1G 330 6120 SCREW 42A9930001
POWER PCB
BOARD / RE
705G 560 87 05 AC SOCKET ASS'Y
050G 500 1 CABLE TIE
071G 100509 FERRITE CORD
087G 501 14 RF AC SOCKET
095G 900582 HARNES
095G8021 5501 WIRE HARNESS
096G 29 6 H.S. TUBE
705G560KF34002 15" LCD ASS'Y
033G4858APM L POWER BUTTON
033G4859 1 C LENS
033G6403APM L CONTROL BUTTON
034G1562APC B BEZEL
705G560KP34005 15" LCD ASS'Y
V000 012G 394 4 RUBBER FOOT
015G8161 1 BASE BRACKET
034G1625 EY B STAND
037G 513 4 HINGE
0Q1G 130 6120 SCREW (T3X6)
0Q1G 140 8120 SCREW T4X8
S37G5134 15"HP LCD HINGE
002F0605300
SCREW NUTS M6.0*P1.0 黑色
004F0612052 00 METAL WASHER
004F061210M 00 METAL WASHERS12.0*6.03*4.70H
004F061210T 00 METAL WASHERS12.0*8.00*1.6H
004F061210T 01 METAL WASHERS12.0*4.72*1.0T
004F0612151 00 WASHER
015F 513010 BRACKET
015F 513030 BRACKET
015F 513420 BRACKET
028F0620090 SHAFT

HP L1506 Specifications

General

3D	No
Pixel pitch	0.297 x 0.297 mm
Aspect ratio	4:3
Response time	8 ms
Display diagonal	15 \
Display resolution	1024 x 768 pixels
Vertical scan range	56 - 76 Hz
Horizontal scan range	30 - 61 kHz
Viewing angle, vertical	100 °
Contrast ratio (dynamic)	-
Contrast ratio (typical)	450:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	130 °
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	720 x 400, 832 x 624, 1024 x 768 (XGA), 640 x 480 (VGA), 800 x 600 (SVGA)
On/off switch	Yes
DVI-D ports quantity	0
Tilt angle range	-5 - 30 °
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	23 W
Power consumption (standby)	2 W
Power consumption (typical)	21 W
Certification	CISPR, VCCI, CSA, TUV, GS, CCC, MIC, FCC, UL, GOST, SASO
Product color	Silver
Country of origin	China
Market positioning	Business
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	5 - 90 %
Package weight	4500 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	203 mm
Height (with stand)	355 mm
Weight (with stand)	3200 g
Depth (without stand)	60 mm
Width (without stand)	340 mm
Height (without stand)	290 mm
Weight (without stand)	- g
