hp L1520/hp L1720/hp L1820 LCD Monitor
Technical Specifications for the hp L1520 Monitor
Technical Specifications for the hp L1520 Monitor
Liquid Crystal
Display (LCD)
Display Size 15 in. (38 cm) diagonal and
viewable image
Type TFT liquid crystal display
Input Signal Video 0.7 V (0,7 V) p-p analog RGB
Synchronization Separated H/V (TTL level)
Interface Input Connector Analog R, G, B separate H,V
sync. 15-pin mini D-SUB +
Digital DVI-D
Scanning
Frequency
Horizontal 30–60 kHz
Vertical 56–75 Hz
Resolution
(H x V)
Maximum 1024 x 768 @ 75 Hz
Recommended 1024 x 768 @ 60 Hz
Power Source AC/DC Adapter Input Rating:
100–240 V~ auto-range, 2 A
max
Output Rating:
12 V , 4.16 A (4,16 A)
Frequency: 50 - 60 Hz
Base Unit Input Voltage: 12 V
Input Current: 2.5 A (2,5 A)
Power
Consumption
Operating mode: 26 W max.
Sleep mode: 3.2 W (3,2 W)
Operating
Environment
Temperature 5° C to 40° C
Humidity 20% RH through 85% RH
(without condensation)
Storage
Environment
Temperature –20° C to 60° C
Humidity 8% RH through 85% RH
(without condensation)
Dimensions
(H x W x D)
With stand 379 to 442 x 353 x 208 mm
(14.9 to 17.4 x 13.9 x 8.2 in)
Without stand 305 x 353 x 48 mm
(12 x 13.9 x 1.9 in)
Weight With stand 4.7kg (4,7kg) 10.4 lb
Tilt Stand Tilt Angle: Down 5, up 25 degrees
Security Lock Monitor cabinet is provided with a slot allowing the use of
Kensington
TM
lock device
