HP L1755 User Manual

Technical Specifications
L1755 Specifications (Continued)
Dimensions
(include pedestal)
Height (bottom of height
16.1 inches 409 mm
adjust range)
Depth
8.3 inches 210 mm
Width
14.4 inches 365 mm
Maximum Graphics Resolution 1280 x 1024 (75 Hz) analog and digital modes
Text Mode 720 x 400
Dot Pitch 0.264 x 0.264 mm
Horizontal Frequency 30 to 82 kHz
(analog mode)
Vertical Refresh Rate 56 to 76 Hz
(analog mode)
Environmental Requirements
Temperature:
Operating Temperature
41to 95
o
F
5 to 35
o
C
Non-operating Temperature
-4 to 140
o
F
-20 to 60
o
C
Relative Humidity 20 to 80%
Power Source 100 - 240 VAC, 60-50 Hz
Power Consumption <40 watts typical
Input Terminals 15-pin D-type connector with cable included.
DVI-I connector (available on select models) with
DVI-D cable and VGA to DVI cable included
B–2 User Guide

HP L1755 Specifications

General

Brand	HP
Model	L1755
Category	Monitor
Language	English
