ENWW
Rear Components
Figure 3-2 Rear Components
Component Function
1 Cable Lock Provision Provides slot for use with cable security locks.
2 Master Power Switch Turns off all power to the monitor.
3 AC Power Connector Connects the AC power cord to the monitor.
4 DVI-I Connectors Connects the DVI-I to VGA signal cable or DVI-D signal
cable to the monitor.
5 USB Upstream
Connector
Connects the monitor USB hub to a host USB port/hub.
6 USB Downstream
Connectors
Connects optional USB devices to the monitor.
7 USB Downstream
Connectors (side panel)
Connects optional USB devices to the monitor.
Chapter 3 Setting Up the Monitor 6
