Installing the Wall mount plate
E69
Install the Wall mount plate.
Wall mount plate(Separate purchase)
mount plate
This is stand-type or wall mount type and is connectable with Wall
mount plate.
Please refer to the installation guide for more details, which is provided
when Wall mount plate is purchased.
Kensington Security Slot
Connected to a locking cable that can be purchased separately at most
computer stores.
Screw Mounting Interface Dimension
Hole spacing : 75 mm x 75 mm.
NOTE
VESA compatible only with respect to screw mounting interface dimensions and
mounting screw specifications
Please use VESA standard as below.
*784.8 mm and under (30.9 inch)
- Wall Mount Pad Thickness : 2.6 mm
- Screw : 4.0 mm x Pitch 0.7 mm x Length 10 mm
* 787.4 mm and above (31.0 inch)
- Please use VESA standard wall mount pad and screws.
