Touchscreen
Specifications
Positional Accuracy
Standard deviation of error is less than 0.080 in (2.03 mm). Equates to less
than ±1% error on most displays.
Touchpoint Density
More than 100,000 touchpoints/in² (15,500 touchpoints/cm²) for a 15-inch
touchscreen. The controller firmware program may reduce resolution to
accommodate axis length greater than 465 mm.
Touch Activation Force
Typically less than 3 ounces (85 grams)
Expected Life
Performance
No known wear-out mechanism, as there are no layers, coatings, or moving
parts. Technology has been operationally tested to more than 50 million
touches in one location without failure, using a stylus similar to a finger.
Surface Durability
Surface durability is that of glass, Mohs' hardness rating of 7
Optical Light
Transmission
(per ASTM
D1003)
Up to 92%
Chemical Resistance
The active area of the touchscreen is resistant to all chemicals that do not
affect glass, such as:
Acetone
Toluene
Methyl ethyl ketone
Isopropyl alcohol
Methyl alcohol
Ethyl acetate
Ammonia-based glass cleaners
Gasoline
Kerosene
Vinegar
Video Input
Plug and Play
Yes
Input Signal
Mini D-Sub 15-Pin VGA type
Input Impedance
75 ohms (2 % value change allowed)
Sync Input
TTL separate synch
Video Cable
Detachable 15-pin D-sub mini connector
Video Cable Length
72 in (1.8 m)
Power
Input Power
100 to 240 VAC
Nominal Current
0.6 Amperes
Frequency
50/60 Hz
Typical Power
Consumption
22 watts
Maximum
30 watts
Sleep
<4 watts
Off
< 2 watts (This monitor does not have an internal sleep function. It needs the
video source in order to go into sleep mode.)
Power Cable Length
72 in (1.8 m); detachable
Mechanical
Dimensions
(H x W x D)
Unpacked with stand
12.2 x 13.8 x 6.9 in (31.0 x 35.0 x 17.5 cm)
Display Head only
11.0 x 13.8 x 2.2 in (28.0 x 35.0 x 5.5 cm)
QuickSpecs
HP L5006tm 15-inch LCD Touchscreen Monitor
Technical Specifications
DA - 12525 North America — Version 8 — April 19, 2013
Page 3
