110 Chapter 4 - Parts and diagrams Q1342-90901
Alphabetical parts list
Table 27. Alphabetical parts list
Description Part number Ref. Figure
Back cover assembly RG0-1016-000CN 4 64
Bushing RA0-1104-000CN 18 70
Cable pod Q1342-60001 1 63
Cable, laser/scanner RG0-1097-000CN 4 65
Clamp, cable WT2-5694-000CN 3 67
Clutch kit RY7-5081-000CN 19 68
Compression spring RA0-1169-000CN 2 65
Connecting link RA0-1023-000CN 7 66
Connector, PCB assembly RG0-1090-000CN 12 65
Control panel assembly RG0-1087-000CN 11 65
Cover, front RA0-1177-000CN 1 64
Cover, left side RA0-1403-000CN 3 64
Cover, right side assembly RF0-1073-000CN 2 64
Cover, right support RA0-1184-000CN 6 65
Delivery sensor PCB assembly RG0-1082-000CN 26 70
Engine controller case RA0-1127-000CN 1 67
Engine controller PCB assembly,
110-127 V
RG0-1093-000CN 4 67
Engine controller PCB assembly,
220-240 V
RG0-1094-000CN 4 67
Face-down delivery assembly RG0-1010-000CN 4 70
Face-down tray assembly RG0-1070-000CN 5 63
Face-up roller RF0-1003-000CN 2 70
Feed-roller holder assembly RG0-1005-000CN 25 68
Foot (plate assemblies) RA0-1197-000CN 10 66
Foot, rubber (paper pickup assembly) RA0-1003-000CN 2 69
Fuser assembly, 110 V RG9-1493-000CN 70
Fuser assembly, 220 V RG9-1494-000CN 70
Fuser plate, left RA0-1185-000CN 3 66
Fuser plate, right RA0-1186-000CN 4 66
Gear, 17T (fuser assembly) RA0-1089-000CN 6 70
Gear, 17T (drive train; left plate side) RA0-1172-000CN 7 65
