Replacing the main input tray (paper-pickup tray assembly)
If you break or damage the main input tray (also called the paper-pickup tray assembly), you can replace
it.
1 Carefully flex the main input tray just enough to release one side.
NOTE Be careful not to break the hinge points.
3
2
1
Figure 5-3 Remove the main input tray
2 Remove the main input tray.
66 Chapter 5 Removal and replacement ENWW
