LaserJet 4 Plus
HP Parts Reference Guide™
Logic/Control Electronics
PC Board
91
RG5-0512-070CN Paper control board - On right side of paper feed assembly
RG5-0966-030CN DC controller board
Optional Interfaces
Interface (Module)
J4101-61011 External JetDirect 300X print server module (10Base-T and 100Base-T) - Connects between printer parallel port and
LAN network - Does NOT include power module - (J4101A, J4101B)
Interface (Product)
J2552B LAN & LocalTalk interface - Has EtherTwist (10Base-T) , ThinLAN (10Base-2) , and LocalTalk (DIN-8) connectors
NO LONGER SUPPLIED
J2555B Token ring LAN interface board - DB-9 and RJ-45 connectors
NO LONGER SUPPLIED
J2556B EtherTwist (10Base-T) or 100Base-TX LAN interface board - Has an RJ-45 connector
NO LONGER SUPPLIED
J2590A External JetDirect LAN interface module with RJ-45 connector for EtherTwist (10Base-T) or 100VG/802.12 input and 3
parallel (DB-25) output connectors
NO LONGER SUPPLIED
J2591A External JetDirect LAN interface module and power module - Has EtherTwist (10Base-T) and ThinLAN (10Base-2)
connectors
NO LONGER SUPPLIED
J3258B External JetDirect 170X LAN interface module - Interfaces a parallel printer to an ethernet 10Base-T (RJ-45) LAN
J3264A External JetDirect 500X token ring interface module - Interfaces up to 3 parallel printers to a token ring (DB-9 or RJ-45)
LAN
J3265A External JetDirect 500X LAN interface module - Interfaces up to 3 parallel printers to an ethernet 10Base-T (RJ-45),
10Base2 (BNC), or 100Base-TX (RJ-45) LAN
J4100A JetDirect 400N modular input/output (MIO) - Internal print server - Provides 10/100Base-T or 10Base-2 network
connection using RJ45 or BNC connectors
J4105A JetDirect 400N modular input/output (MIO) internal print server - Provides token ring network connection using RJ45 or
DB9 connectors
J4106A JetDirect 400N modular input/output (MIO) internal print server - Provides 10Base-T network connection using RJ45
connector
Module
J2382-69003 External JetDirect LAN interface module with ethertwist (10Base-T) and ThinLAN (10BASE-2) connectors
J2383-61005 External token ring interface module - Has DB-9 connector
J2590-69001 External JetDirect LAN interface module with RJ-45 connector for ethertwist (10Base-T) or 100VG/802.12 input and 3
parallel (DB-25) output connectors
REQUIRES RETURN OF DEFECTIVE PART
J2590-61011 New Part for J2590-69001
J2591-69001 External JetDirect LAN interface module with ethertwist (10Base-T) and ThinLAN (10BASE-2) connectors
J2592-69001 External JetDirect LAN interface module with ethertwist (10Base-T) connector
REQUIRES RETURN OF DEFECTIVE PART
J2592-61001 New Part for J2592-69001
J2593-69001 External JetDirect LAN interface module with Ethertwist (10Base-T) and ThinLAN (10BASE-2) input connectors and 3
parallel (DB-25) output connectors - (part of J2593A)
J2594-69001 External JetDirect token ring interface module with DB-9 and RJ-45 input connectors and 3 parallel (DB-25) output
connectors - (part of J2594A)
REQUIRES RETURN OF DEFECTIVE PART
J2594-61011 New Part for J2594-69001
J3258-61011 External JetDirect LAN interface module with EtherTwist (10Base-T) connector - (J3258A, J3258B)
J4102-69011 External JetDirect LAN interface module with EtherTwist (10Base-T) connector - (J4102A, J4102B)
REQUIRES RETURN OF DEFECTIVE PART
J4102-61011 New Part for J4102-69011
© 2004 Hewlett-Packard 5
