REF PART NO. QTY DESCRIPTION
1 RG5-1801-000CN
RG5-2776-000CN
1 Fan Assembly (5P/5MP)
Fan Assembly (6P/6MP)
2 RB1-6006-000CN 1 Arm, Sensor
3 RB1-6332-000CN 1 Pick-Up Roller (tray 2)
4 RG5-1692-000CN
RG5-2796-000CN
Pick-Up Assy (tray 2) (5P/5MP)
Pick-Up Assy (tray 2) (6P/6MP)
5 RG5-1799-000CN
RG5-2786-000CN
1 Motor Assembly (5P/5MP)
Motor Assembly (6P/6MP)
6 C3150-00005
C3980-00007
1 Formatter Shield (5P/5MP)
Formatter Shield (6P/6MP)
7 C3152-69001
C3987-69001
1 PostScript SIMM (exch.) (5P/5MP)
PostScript SIMM (exch.) (6P/6MP)
8 C3151-67901
C3151-69001
C3981-69001
1 Formatter PCA (new)
Formatter PCA (exch.) (5P/5MP)
Formatter PCA (exch.) (6P/6MP)
9 0515-2701 2 TORX screws
10 RB1-5971-000CN 1 Leaf Spring
11 RG5-1713-000CN
RG5-2778-000CN
1 Gear train Assembly (5P/5MP)
Gear train Assembly (6P/6MP)
12 RB1-5999-000CN
RB1-9195-000CN
1 Plate, Grounding, Left (5P/5MP)
Plate, Grounding, Left (6P/6MP)
13 RB1-5998-000CN
RB1-9194-000CN
1 Plate, Grounding, Right (5P/5MP)
Plate, Grounding, Right (6P/6MP)
Table 14.
Internal Components (1)
HP LaserJet 5P/5MP, 6P/6MP Printer Service Supplement
Parts and Diagrams
