Assembly locations
Base product (no optional trays or accessories)
Figure 3-1 Base product (no optional trays or accessories)
Table 3-5 Base product
Item Description Item Description
1 Face-down output bin 6 Rear door assembly
2 Control panel 7 Input tray
3 Power switch 8 Front door
4 Extension tray 9 Top door assembly
5 Power receptacle
