Locations of major components
Figure 2-4 External view
1
2
3
4
5
6
7
8
9
Item Description Item Description
1 Top door assembly 6 Rear door assembly
2 Control panel 7 Rear top cover
3 Right cover 8 Input tray
4 Left cover 9 Front door
5 rear bottom cover
