Table 3-7 Internal components (1 of 4)
Ref Description Part number Qty
1 Roller, separation Assembly RM1-4425-000CN 1
2 Roller, pickup assembly RM1-4426-000CN 1
3 Drive assembly, priority slot RM1-4459-000CN 1
4 Feed assembly, priority RM1-7854-000CN 1
5 Cassette assembly RM1-7704-000CN 1
6 Fuser power supply assembly (220V-240V) RM1-7083-000CN 1
6 Fuser power supply assembly (110V-127V) RM1-7082-000CN 1
7 Cover, holder RC2-2014-000CN 1
ENWW Internal assemblies 125
