Table 15-3 Passes, resolutions, and speeds (continued)
Passes Ink density
Resolution (ppi)
Printing speed (m²/
h)
Printing speed (ft²/
h)
Rendering Printing 3.2 m roll 3.2 m roll
10 ≤ 300%
600 × 600 600 × 1200 44 474
14 ≤ 300% 600 × 600 600 × 1200 35 377
18 131–300% 600 × 600 600 × 1200 27 291
18 ≤ 130% 600 × 600 1200 × 1200 22 237
Table 15-4 Standard print modes
Print mode name Viewing distance Print mode Printing speed (m²/h) Printing speed (ft²/h)
Textile 1–3 m 14p 6c 260% 35 377
Backlit 1–3 m 14p 6c 230% 35 377
Indoor high quality 1–3 m 6p 6c 100% 77 829
Outdoor plus 3–5 m 4p 6c 80% 98 1055
Outdoor 3–5 m 3p 6c 60% 120 1292
Billboard > 5 m 2p 4c 50% 180 1938
Draft > 5 m 1p 4c 40% 315 3391
Physical specifications
Table 15-5 Printer physical specifications
Weight 1500 kg (3307 lb) without crate
Width 5.979 m (235.4 in)
Depth 1.715 m (67.52 in)
Height 1.673 m (65.87 in)
Memory specifications
Table 15-6 Memory specifications for the Internal Print Server computer
Memory (DRAM) supplied 4 GB
Hard disk 160 GB
Power specifications
The drying and curing components are powered with a three-phase line that requires a power distribution
unit (PDU).
262 Chapter 15 Printer specifications ENWW
