HP LD4730 - Page 4

Text Mode 720 x 400 @ 70 Hz
Mac Mode 832 x 624 @ 75 Hz
Maximum Pixel Clock Speed 160 MHz
User Programmable Modes Yes, 20
Anti-Glare Yes
Anti-Static Yes
Default Color Temperature 9300K
Video/
Other Inputs
(see Figure A-1
below)
RS232C 1 input and 1 output
Input Signal VGA (RGB), DisplayPort (DP)
Output VGA (RGB) and DisplayPort (DP) out for tiling
USB USB input for color calibration and firmware update.
LAN (RJ45) 1 input; command and control and video over Ethernet.
Audio 1 audio input jack, AUDIO connects the audio cable to the Line Out on the media
player/computer sound card.
Speaker Connects the external speakers (not included) to the display.
IR Input/output; for receiving and sending the IR control signals
Plug and Play Yes
Input Impedance 75 Ohms ± 10%
Sync Input TTL separate sync
VGA Cable Length 1,8 m (5.9ft )
DisplayPort Cable Length 1,8 m (5.9ft )
IR Cable Length 1,8 m (5.9ft )
Figure A-1
Power Input Power 100 - 240 VAC
Frequency 50/60 Hz
Typical Power Consumption 180 W
Maximum 250 W
Power Saving Sleep: 0.5 W
Power Cable Length 1,9 m (6.2 ft )
Mechanical LD4730 Dimensions
(H x W x D)
See Figures B-3 and B-4 below.
Unpacked w/o stand (feet) or
speakers (head only)
59,16 x 104,68 x 9 cm
(23.3 x 41.2 x 3.5 in)
Packaged 75,3 x 122,7 x 25,5 cm
(29.65 x 48.31 x 10.04 in )
LD4730 Weight - maximum Unpacked w/o stand (feet) or
speakers (head only)
23,8 kg (52.5 lbs)
Packaged 29,0 kg (63.93 lbs)
Figure B-3 - HP LD4730 Front View
QuickSpecs
HP LD4730 47-inch Micro-Bezel Video Wall Display
HP LD4730G 47-inch Micro-Bezel Video Wall Display with
Protective Glass
Technical Specifications
DA - 14248 North America — Version 3 — April 18, 2013 Page 4
