HP LP3065 Specification

life.
Packaging Materials
Corrugated Paper – 2.19 kg
PE-LD Bags – 0.09 kg
EPS Molded Foam – 1.07 kg
RoHS Compliance Hewlett-Packard is committed to compliance with all applicable
environmental laws and regulations, including the European Union
Restriction of Hazardous Substances (RoHS) Directive. HP's goal is to
exceed compliance obligations by meeting the requirements of the
RoHS Directive on a worldwide basis. By July 1, 2006, RoHS
substances will be virtually eliminated (virtually = to levels below legal
limits) for all HP electronic products subject to the RoHS Directive,
except where it is widely recognized that there is no technically feasible
alternative (as indicated by an exemption under the EU RoHS
Directive).
Material Usage This product does not contain any of the following substances in
excess of regulatory limits (refer to the HP General Specification for the
Environment at www.hp.com/hpinfo/globalcitizenship/
environment/supplychain/gen_specifications.html ):
Asbestos
Certain Azo Colorants
Certain Brominated Flame Retardants – may not be used as
flame retardants in plastics
Cadmium
Chlorinated Hydrocarbons
Chlorinated Paraffins
Formaldehyde
Halogenated Diphenyl Methanes
Lead carbonates and sulfates
Lead and Lead compounds
Mercuric Oxide Batteries
Nickel – finishes must not be used on the external surface
designed to be frequently handled or carried by the user.
Ozone Depleting Substances
Polybrominated Biphenyls (PBBs)
Polybrominated Biphenyl Ethers (PBBEs)
Polybrominated Biphenyl Oxides (PBBOs)
Polychlorinated Biphenyl (PCB)
Polychlorinated Terphenyls (PCT)
Polyvinyl Chloride (PVC) – except for wires and cables, and
certain retail packaging has been voluntarily removed from most
applications.
Radioactive Substances
Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)
Packaging HP follows these guidelines to decrease the environmental impact of
product packaging:
Eliminate the use of heavy metals such as lead, chromium,
mercury and cadmium in packaging materials.
Eliminate the use of ozone-depleting substances (ODS) in
packaging materials.
Design packaging materials for ease of disassembly.
Maximize the use of post-consumer recycled content materials in
QuickSpecs
HP LP3065 30-inch Widescreen LCD Monitor
Technical Specifications
DA - 12621 Worldwide QuickSpecs — Version 16 — 12/15/2008 Page 4

HP LP3065 Specifications

General

Pixel pitch	0.250 mm
Response time	6 ms
Display diagonal	30 \
Display resolution	2560 x 1600 pixels
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Display scanning frequency	Horizontal frequency: 100 kHz, Vertical frequency: 60 Hz
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	2560 x 1600 (WQXGA)
UNSPSC-code	43211902
On/off switch	Yes
Audio included	No audio includedNo audio included at platform level
Security features	Kensington Lock-ready
Weight (imperial)	Unpacked30.6 lb lbs
Power requirements	Auto-Sensing, 100 to 240 VAC, 50 +/-3 Hz to 60 +/-3 Hz)
Display resolution at frequency	2560 x 1600 @ 60 Hz (native)
Dimensions (W x D x H) (imperial)	27.2 x 3.3 x 17.9 \
Product dimensions (with stand, imperial)	27.2 x 9.5 x 23.2 \
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Non-operating relative humidity (non-condensing)	5 - 85 %
Tilt angle range	-5 - 30 °
Height adjustment	100 mm
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
Power consumption (standby)	2 W
Power consumption (typical)	118 W
Certification	Australian ACA Approval, Canadian Requirements/CSA, CE Marking, China CCIB/CCEE Approval, CISPR Requirements, Eastern European Approvals, FCC Approval, German Ergonomic (TUV and GS Mark), ISO 9241-3, 7, 8 VDT Guidelines, ISO 13406-2 Pixel Defect Guidelines, Mexican NOM Approval, MIC Requirements (New Zealand), MPR-II Compliant, Nordic Approvals (Nemko, Fimko, Demko, Semko), S. Korean MIC Approval, Taiwan BSMI Approval, TCO 99 (emissions, ergonomics, environment), TUV-Ergo, UL Listed, VCCI Approvals, Microsoft Windows Certification (Microsoft Windows 98, Microsoft Windows 2000, and Microsoft Windows XP)
Product color	Black
Country of origin	China
I/O ports	One upstream, four downstream USB 2.0 Hub ports (cable included)
USB hub version	2.0
DVI-D ports quantity	3
DVI-I ports quantity	0
USB upstream port type	USB Type-B
USB Type-A downstream ports quantity	4

Weight and Dimensions

Depth (with stand)	240 mm
Height (with stand)	590 mm
Weight (with stand)	13400 g
Depth (without stand)	84 mm
Width (without stand)	692 mm
Height (without stand)	455 mm
