Booklet maker
1
2
4 5 6 7
3
9
8
10
11
12
13
1 Booklet output bin
2 Booklet output slot
3 Stapler/stacker output bins
4 Stapler/stacker output slot
5 Front door
6Top cover
7 Upper release latch
8Stapler 1
9 Upper paper delivery guide
10 Lower paper delivery guide
11 Saddle-stitch carriage, access to stapler 2 and stapler 3
12 Paper-advancement knobs for clearing jams
13 Lower release latch
12 Chapter 1 Product introduction ENWW
