List the type and size of the tools that would typically be used to disassemble the product to a point where components
and materials requiring selective treatment can be removed.
Tool Size (if
applicable)
3.0 Product Disassembly Process
3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment:
1. Unscrew the screws on part 1, and then remove part 1.
2. Unscrew the screws on part 2, and then remove part 2.
3. Unscrew the screws on part 3, and then remove part 3 and part 5.
4. Unscrew the screws on part 6, and then remove part 6.
3.2 Optional Graphic. If the disassembly process is complex, insert a graphic illustration below to identify the items
contained in the product that require selective treatment (with descriptions and arrows identifying locations).
Figure 1 Remove part 1 Figure 2 Remove part 2
Figure 3 Treatments to the product Figure 4 Treatments to the product
EL-MF877-00 Page 2
Template Revision B
