Printing supplies area
1Ink cartridges
2 Printhead
3 Ink cartridges access door
NOTE: Ink cartridges should be kept in the printer to prevent possible print quality issues or printhead
damage. Avoid removing supplies for extended periods of time. Do not turn the printer off when a cartridge is
missing.
Back view
1 Fax port (1-LINE)
2Fax port (2-EXT)
3 Ethernet network port
4 Power input
5 Rear USB port
6 Rear access panel
ENWW Understand the printer parts 5
