11. Mechanical Instructions
Step Figure Description
Remove
the Stand
-Base
ASSY.
The model using the
curved surface
screen; There must
be put soft mat
above of the work
station and don't
push hard on the
machine to avoid
cause screen to
crack. Loose the
screws to remove the
stand-base assy.
Remove
the Rear
Cover
Use disassembly tool
to open all the
latches along the
edge of the Rear
Cover
Remove
the pins
Remove the pins
